Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 700c -
Groupset GRX 800, FSA -
Suspension Rigid -
Motor Fazua 250W 55Nm mid-drive -
Battery Fazua Evation 250Wh with charger -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
160cm - 170cm
MD
168cm - 178cm
LG
175cm - 183cm
XL
180cm - 188cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
A6-SL Super-Butted Aluminum, internal cable routing, , Fazua compatible, integrated head tube w/ 1 1/2" upper and lower, double water bottle mounts, flat-mount disc system, dropout w/ 12mm replaceable hanger
Suspension Fork
FC-440 Cross carbon monocoque, 12mm thru-axle w/ flat-mount disc tabs, tapered steerer, rack/water bottle mounts
Drivetrain
Rear Derailleur
Shimano GRX RX812 GS
Shift Levers
Shimano GRX Dual Control Hydraulic, 11-speed
Cassette
Shimano HG-5100-11, 11-42T
Crank
FSA CK-746-1/IS, 42T Megatooth, for Fazua
Chain
Shimano HG601-11, HyperGlide-X, 11-speed
Wheels
Rims
WTB HTZ i23 TCS 2.0, 32/32h, 12mm thru-axle cartridge bearing hubs for e-gravel
Tires
WTB Riddler, 700x45c, Dual DNA Compound, Lightweight Tubeless Casing, TCS Aramid Bead, Tan walls
Brakes
Brakes
Shimano GRX Hydraulic, 160/160mm rotors
Brake Levers
Shimano GRX Hydraulic
Cockpit
Stem
FSA ST-OS-185 for SMR system, 6061 alloy, 31.8mm clamp, -6°, length: S: 90mm / M: 100mm / L-XL: 110mm
Handlebar
Fuji, 6061 alloy, 31.8mm clamp, 125mm drop, 25° flare, 4° sweep, width: S: 400mm / M: 420mm / L-XL: 440mm
Grips
Anti-slip silicone
Headset
FSA NO.55R / 1.5"-1.5" / SMR system / ACB bearings
Seat
Saddle
Oval Concepts 300, steel rail
Seatpost
FSA Energy, 6066 alloy micro adjust, 27.2mm diameter, 350mm length
Motor & Battery
Motor
Fazua Evation mid-motor, 250W rated power, 55Nm of torque, 20mph maximum assist
Battery
Fazua Evation 250Wh with charger
Remote
Fazua Evation Satellite remote
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.5 mm | 1.54 mm | 1.58 mm |
| Bottom Bracket Height | 277 mm | 277 mm | 277 mm | 277 mm |
| Front Center | 602 mm | 613 mm | 623 mm | 633 mm |
| Rake | 48 mm | 48 mm | 48 mm | 48 mm |
| Trail | 73 mm | 69 mm | 66 mm | 63 mm |
| Stack | 557.7 mm | 583.3 mm | 609 mm | 634.7 mm |
| Reach | 381.7 mm | 389 mm | 395.4 mm | 402.5 mm |
| Top Tube Length | 535 mm | 555 mm | 580 mm | 595 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73 ° | 73 ° |
| Seat Tube Length | 490 mm | 530 mm | 560 mm | 590 mm |
| Head Tube Angle | 70.5 ° | 71 ° | 71.5 ° | 72 ° |
| Head Tube Length | 125 mm | 150 mm | 175 mm | 200 mm |
| Chainstay Length | 437 mm | 437 mm | 437 mm | 437 mm |
| Wheelbase | 1028 mm | 1040 mm | 1049 mm | 1060 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 72 mm | 72 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 160 cm | 168 cm | 175 cm | 180 cm |
| Rider Max Height | 170 cm | 178 cm | 183 cm | 188 cm |
About this model
E-Jari completes the Fuji E E Jari model. Fuji launched 4 e-bikes of this model so far.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Gravel e-bikes average price
According to our calculations, the average cost of a Gravel e-bike that is reliable is 3642$. However, you could also get a good Gravel e-bike even if you pay a lower amount than the average price. To sum up, when you purchase your e-bike, make sure to check if it has reviews, and also do some components research.
When Fuji released this model in 2021, its price was 4999$. Doing a quick comparison, we notice that E-Jari price is 37.26% more expensive than the average cost of a Gravel e-bike.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
E-Jari components
Fork material
E-Jari has a carbon fork, so, it’s a great addition to the e-bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
The wheels on E-Jari are the 700c aluminum type. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Fuji E-Jari is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
Fuji E-Jari e-bike has 4 sizes, in the range of 160 cm – 188 cm (5.25 ft – 6.17 ft). In conclusion, you won’t have a problem finding one that suits you.
