Fuji E-Traverse 2.1 ST 2025
2025 E-bike
Estimate price |
1,499$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 63mm -
Fork Suntour NEX
-
Groupset Tourney, Altus -
Suspension Hardtail -
Motor Bafang 250W hub-drive -
Battery Fuji Power Pack 417Wh w/ 2A charger -
Drivetrain 3 × 8 -
Brakes Shimano Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fuji A2-SL Custom-Butted Alloy, integrated head tube, down tube battery mount, fender and rack mounts
Suspension Fork
Suntour NEX disc, 700C coil, travel 63mm, steel steerer
Drivetrain
Rear Derailleur
Shimano Altus M310
Front Derailleur
Shimano Tourney TY710
Shift Levers
Shimano Altus M310, Rapid Fire
Cassette
Shimano Acera HG31, 11-32T, 8-speed
Crank
Shimano TY-301, 48/38/28T w/ chainring guard
Bottom Bracket
Bafang sealed cartridge BB with cadence sensor
Chain
KMC X8 w/ Missing Link, EPT anti-rust, 8-speed
Pedals
Aluminum body, chromoly axle
Wheels
Rims
Shimano TX505 CL disc, 36H, front, Bafang rear motor hub, 6 bolt disc, 36H, stainless steel spokes, Vera Corsa DPD17 aluminum double wall rims
Tires
Vera Traverse 700 x 47c, E Line 50 w/ Phalanx puncture protection, reflective stripe
Brakes
Brakes
Shimano MT200 hydraulic disc, rotors: 180mm front, 160mm rear
Brake Levers
Shimano MT200 hydraulic 3 finger lever
Cockpit
Stem
Fuji, forged aluminum, +/-6 degree
Handlebar
Oval Concepts riser bar, 6061 alloy, 15mm rise, 5 degree sweep, 31.8mm clamp
Grips
Oval Concepts Comfort, single density Kraton
Headset
1 1/8", zero stack, sealed, caged bearings
Seat
Saddle
Oval Sport, steel rail
Seatpost
Oval Concepts, 6061 alloy micro adjust, 27.2mm diameter
Motor & Battery
Motor
Bafang H400B rear hub motor, 250W rated power, 20mph or 25kph maximum assist
Battery
Fuji Power Pack 417Wh w/ 2A charger
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.801 mm | 1.752 mm | 1.812 mm | 1.802 mm |
| Front Center | 607 mm | 619 mm | 602 mm | 612 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 84 mm | 83 mm | 79 mm | 79 mm |
| Stack | 634 mm | 636 mm | 645 mm | 654 mm |
| Reach | 352 mm | 363 mm | 356 mm | 363 mm |
| Top Tube Length | 547 mm | 558 mm | 565 mm | 575 mm |
| Seat Tube Angle | 73 ° | 73 ° | 72 ° | 72 ° |
| Seat Tube Length | 381 mm | 432 mm | 483 mm | 533 mm |
| Head Tube Angle | 70 ° | 70 ° | 71 ° | 71 ° |
| Head Tube Length | 155 mm | 160 mm | 160 mm | 170 mm |
| Chainstay Length | 460 mm | 460 mm | 460 mm | 460 mm |
| Wheelbase | 1060 mm | 1072 mm | 1055 mm | 1065 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 692 mm | 689 mm | 692 mm | 697 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
