Fuji Nevada 26 1.9 V 2025
2025 Mountain
Estimate price |
615$
Weight | 13.64 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Travel Front 100mm -
Groupset Tourney -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Shimano Tourney Rim
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
159cm - 170cm
MD
165cm - 177cm
LG
171cm - 184cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fuji A2-SL custom-butted alloy front triangle, Fuji A1-SL alloy rear triangle
Suspension Fork
CH-565AMS, 100mm
Drivetrain
Rear Derailleur
Shimano Tourney
Front Derailleur
Shimano Tourney
Shift Levers
Shimano EF41, EZ Fire, 3 x 7-speed
Cassette
Shimano TZ500 freewheel, 14-34T
Crank
Prowheel, 42/34/24T
Bottom Bracket
Sealed cartridge bearing
Chain
KMC HV500
Pedals
Resin platform
Wheels
Rims
Fuji Aluminum rims 36h, Formula FM-21 front, FM-31 rear hubs, black spokes
Tires
Kenda K1153, 26" x 2.1", 27tpi
Brakes
Brakes
TX-117 V-Brake
Brake Levers
Shimano EF41
Cockpit
Stem
Fuji, forged aluminum, +/-6°
Handlebar
Hi-Ten, riser, 30mm rise, 700mm
Grips
Fuji Performance Grip
Headset
1 1/8" sealed bearings
Seat
Saddle
Fuji Performance Saddle
Seatpost
Fuji, alloy, 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.541 mm | 1.537 mm | 1.462 mm | 1.4 mm |
| Bottom Bracket Height | 309 mm | 309 mm | 309 mm | 309 mm |
| Front Center | 599 mm | 609 mm | 642 mm | 665 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 77 mm | 77 mm | 83 mm | 77 mm |
| Stack | 555.2 mm | 564.6 mm | 584.3 mm | 583.4 mm |
| Reach | 360.3 mm | 367.4 mm | 399.6 mm | 416.6 mm |
| Top Tube Length | 530 mm | 540 mm | 575 mm | 595 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 330 mm | 381 mm | 432 mm | 482 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm | 140 mm |
| Chainstay Length | 425 mm | 425 mm | 425 mm | 425 mm |
| Wheelbase | 1021 mm | 1032 mm | 1064 mm | 1088 mm |
| Bottom Bracket Drop | 34 mm | 34 mm | 34 mm | 34 mm |
| Standover Height | 717 mm | 745 mm | 786 mm | 801 mm |
| Wheels | 26" | 26" | 26" | 26" |
| Rider Min Height | 151 cm | 159 cm | 165 cm | 171 cm |
| Rider Max Height | 164 cm | 170 cm | 177 cm | 184 cm |
