Fuji Nevada 29 2.0 LTD 2025
2025 Mountain
Estimate price |
1,046$
Weight | 14.96 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Travel Front 100mm -
Fork Suntour XCM
-
Groupset Deore -
Suspension Hardtail -
Drivetrain 2 × 10 -
Brakes Shimano Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fuji A2-SL custom-butted alloy front triangle, Fuji A1-SL alloy rear triangle
Suspension Fork
SR Suntour SF20-XCM-HLO-DS-29, 100mm
Drivetrain
Rear Derailleur
Shimano Deore
Front Derailleur
Shimano Deore
Shift Levers
Shimano Deore, 2 x 10-speed
Cassette
Shimano CS-M4100-10, 11-42T
Crank
Shimano Deore, 36/26T
Bottom Bracket
Shimano, threaded
Chain
KMC X10
Pedals
Resin platform
Wheels
Rims
WTB SX19 rims 32H, Shimano HB-TX505 front, FH-TX505 rear hub, stainless black spokes
Tires
WTB Ranger Comp, 29" x 2.25", 27tpi
Brakes
Brakes
Shimano MT200, 180/160mm rotors
Brake Levers
Shimano MT200
Cockpit
Stem
Fuji, forged aluminum, +/-6°
Handlebar
Fuji flat bar, alloy, 710mm
Grips
Fuji Performance Grip
Headset
1 1/8" sealed bearings
Seat
Saddle
WTB Volt Sport
Seatpost
Fuji, alloy, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL | XXL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.475 mm | 1.406 mm | 1.383 mm | 1.356 mm |
| Bottom Bracket Height | 319 mm | 319 mm | 319 mm | 319 mm |
| Front Center | 690 mm | 715 mm | 733 mm | 752 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm |
| Trail | 94 mm | 94 mm | 94 mm | 94 mm |
| Stack | 621 mm | 625.5 mm | 635 mm | 644 mm |
| Reach | 421 mm | 445 mm | 459 mm | 475 mm |
| Top Tube Length | 611 mm | 636 mm | 653 mm | 672 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 420 mm | 470 mm | 520 mm | 560 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 105 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 450 mm | 450 mm | 450 mm | 450 mm |
| Wheelbase | 1134 mm | 1160 mm | 1177 mm | 1197 mm |
| Bottom Bracket Drop | 55 mm | 55 mm | 55 mm | 55 mm |
| Standover Height | 809 mm | 834 mm | 862 mm | 886 mm |
| Wheels | 29" | 29" | 29" | 29" |
