Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 140mm -
Travel Rear 120mm -
Fork RST VIBE
-
Groupset Deore -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Tektro Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fuji A6-SL super-butted alloy front and rear triangle, Enduro Max sealed cartridge bearings, MLink patented suspension system, Boost 148x12mm, 120mm
Suspension Fork
RST Vibe 110-15 Air, tapered alloy steerer, Boost 110x15mm, 140mm travel
Rear Shock
X-Fusion O2 Pro R
Drivetrain
Rear Derailleur
Shimano Deore, shadow plus
Shift Levers
Shimano Deore, 1 x 11-speed
Cassette
Sunrace, 10-50T
Crank
Prowheel, 30T
Bottom Bracket
External cup, threaded
Chain
KMC X11
Wheels
Rims
Alex DP30 tubeless ready 32H, Formula DC-511 front hub, DC-3248 rear hub, stainless spokes
Tires
Maxxis Forecaster, 29" x 2.35", 60tpi
Brakes
Brakes
Tektro M275, 180mm rotors
Brake Levers
Tektro M275
Cockpit
Stem
TranzX, alloy, +0 degree rise
Handlebar
TranzX Riser Bar, alloy, 20mm rise, 780mm
Grips
WTB Waffel, Lock on
Headset
FSA 1 1/8" - 1.5", sealed cartridge bearings
Seat
Saddle
Selle San Marco Monza Full Fit Start Up
Seatpost
Fuji, alloy, 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.351 mm | 1.313 mm | 1.278 mm | 1.245 mm |
| Bottom Bracket Height | 342 mm | 342 mm | 342 mm | 342 mm |
| Front Center | 766 mm | 790 mm | 814 mm | 838 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 128 mm | 128 mm | 128 mm | 128 mm |
| Stack | 607.9 mm | 616.9 mm | 626 mm | 635 mm |
| Reach | 450 mm | 470 mm | 490 mm | 510 mm |
| Top Tube Length | 590 mm | 618 mm | 646 mm | 668.5 mm |
| Seat Tube Angle | 77 ° | 76.5 ° | 76 ° | 76 ° |
| Seat Tube Length | 380 mm | 420 mm | 458 mm | 495 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 431 mm | 431 mm | 431 mm | 431 mm |
| Wheelbase | 1194 mm | 1219 mm | 1243 mm | 1267 mm |
| Bottom Bracket Drop | 32 mm | 32 mm | 32 mm | 32 mm |
| Standover Height | 748 mm | 766 mm | 762 mm | 783 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
