Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 170mm -
Travel Rear 150mm -
Fork RockShox Yari RC
-
Groupset SX Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes TRP Slate EVO Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fuji A6-SL super-butted alloy front and rear triangle, Enduro Max sealed cartridge bearings, MLink patented suspension system, Boost 148x12mm, 150mm
Suspension Fork
RockShox Yari RC 29 DebonAir, tapered alloy steerer, Boost 110x15mm, 170mm
Rear Shock
RockShox Super Deluxe Coil Select
Drivetrain
Rear Derailleur
SRAM SX Eagle
Shift Levers
SRAM SX Eagle, 1 x 12-speed
Cassette
SRAM PG-1210, 11-50T
Crank
SRAM SX Eagle, 32T
Bottom Bracket
SRAM DUB, threaded
Chain
SRAM SX Eagle
Wheels
Rims
WTB ST i30 TCS 2.0 32H, Formula DC-711 front hub, DC-3248 rear hub, DT Swiss Industry stainless spokes
Tires
Maxxis Assegai, 29" x 2.50" WT, 60tpi, EXO, Tubeless Ready, folding, Maxxis Minion DHR II, 29" x 2.40" WT, 60tpi, EXO, Tubeless Ready, folding
Brakes
Brakes
TRP Slate EVO, 203/180mm rotors
Brake Levers
TRP Slate EVO
Cockpit
Stem
TranzX, alloy, +0 degree rise
Handlebar
TranzX Riser Bar, alloy, 20mm rise, 780mm
Grips
WTB Waffel, Lock on
Headset
FSA 1 1/8" - 1.5", sealed cartridge bearings
Seat
Saddle
Selle Italia X3 Boost
Seatpost
TranzX JD-YSP18P, 31.6mm, 15" - 130mm travel, 17, 19, 21" - 150mm travel, PLQ Lever
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.36 mm | 1.321 mm | 1.286 mm | 1.253 mm |
| Bottom Bracket Height | 347 mm | 347 mm | 347 mm | 347 mm |
| Front Center | 789 mm | 813 mm | 838 mm | 863 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 140 mm | 140 mm | 140 mm | 139 mm |
| Stack | 612 mm | 621 mm | 630 mm | 639 mm |
| Reach | 450 mm | 470 mm | 490 mm | 510 mm |
| Top Tube Length | 586 mm | 613 mm | 641 mm | 663.5 mm |
| Seat Tube Angle | 77.5 ° | 77 ° | 76.5 ° | 76.5 ° |
| Seat Tube Length | 380 mm | 420 mm | 458 mm | 495 mm |
| Head Tube Angle | 63.5 ° | 63.5 ° | 63.5 ° | 63.5 ° |
| Head Tube Length | 90 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1224 mm | 1248 mm | 1273 mm | 1298 mm |
| Bottom Bracket Drop | 27 mm | 27 mm | 27 mm | 27 mm |
| Standover Height | 747 mm | 760 mm | 763 mm | 760 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
