Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Travel Front 100mm -
Fork Fox Performance Float 32
-
Groupset XT -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Shimano XT Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
C10 super-light high-modulus carbon, BB92, Boost 148x12mm
Suspension Fork
Fox 32 FLOAT 29 Performance SC GRIP, remote lockout, tapered alloy steerer, Boost 110x15mm, 100mm
Drivetrain
Rear Derailleur
Shimano Deore XT, shadow plus
Shift Levers
Shimano Deore XT, 1 x 12-speed
Cassette
Shimano Deore XT, 10-51T
Crank
Shimano Deore XT, 32T
Bottom Bracket
Shimano BB92, press fit
Chain
Shimano SLX
Wheels
Rims
WTB Speedterra ST i27 TCS 2.0 wheelset, 32H
Tires
Maxxis Rekon Race, 29" x 2.35", 60tpi, EXO, Tubeless Ready, folding
Brakes
Brakes
Shimano Deore XT, 180/160mm rotors
Brake Levers
Shimano Deore XT
Cockpit
Stem
Race Face Ride, 6° rise
Handlebar
Race Face Ride Flat Bar, 710mm
Grips
Fuji Performance Grip Lock On
Headset
FSA 1 1/8" - 1.5", sealed cartridge bearings
Seat
Saddle
Selle Italia X1
Seatpost
Race Face Ride XC, 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.556 mm | 1.484 mm | 1.443 mm | 1.424 mm |
| Bottom Bracket Height | 314 mm | 314 mm | 314 mm | 314 mm |
| Front Center | 656 mm | 681 mm | 701 mm | 722 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 86 mm | 83 mm | 86 mm | 86 mm |
| Stack | 610.6 mm | 615.3 mm | 624.7 mm | 638.7 mm |
| Reach | 392.5 mm | 414.6 mm | 433 mm | 448.6 mm |
| Top Tube Length | 585 mm | 610 mm | 630 mm | 650 |
| Seat Tube Angle | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 395 mm | 440 mm | 483 mm | 533 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 100 mm | 105 mm | 115 mm | 130 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1083 mm | 1109 mm | 1129 mm | 1150 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 744 mm | 769 mm | 801 mm | 839 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
