Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 700c -
Groupset Ultegra, 105 -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Rim
Sizing
Recommended size guide.
49cm
155cm - 163cm
52cm
161cm - 169cm
54cm
166cm - 175cm
56cm
172cm - 181cm
58cm
178cm - 186cm
61cm
183cm - 191cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Monoque C-4 carbon with custom weave carbon strands, Integrated aluminum cupped head tube, Double water bottle mounts.
Suspension Fork
FC-770 Fuji Bonded Carbon Integrated w/ 1 1/8" Alloy Steerer
Drivetrain
Rear Derailleur
Shimano Ultegra
Front Derailleur
NEW Shimano 105 F-Type
Shift Levers
NEW Shimano 105 shifter/brake, 20-speed Flight Deck compatible
Cassette
New Shimano 105, 12-27T 10-speed
Crank
NEW TruVativ Elita Compact GXP, w/Integrated spindle 36/50T alloy rings
Bottom Bracket
Truvativ GXP Exterior Bearing System
Chain
New Shimano 105, 10sp
Pedals
none
Wheels
Front Hub
Alex AKX-R1.0 28H
Rear Hub
Alex AKX-R1.0, 32H
Rims
Alex AKX-R1.0 Double Wall Aluminum
Spokes
14g Stainless
Tires
Continental UltraSport, 700 x 23c
Brakes
Brakes
Cane Creek SCR-3 w/ cartridge pads
Brake Levers
NEW Shimano 105 Shifter/Brake, Flight Deck compatible
Cockpit
Stem
Fuji Pro AL 3D forged, +/-6 degree
Handlebar
Fuji UltraLite 6061 Double Butted, 31.8mm w/Anatomical drops
Headset
V.P. 1 1/8" Integrated Road, with convex hollow alloy Spacer
Seat
Saddle
Fuji UltraLite Racing
Seatpost
Fuji PRO Forged alloy, 300mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 49cm | 52cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Bottom Bracket Height | 281 mm | 281 mm | 281 mm | 281 mm | 281 mm | 281 mm |
| Front Center | 576 mm | 582 mm | 576 mm | 586 mm | 596 mm | 600 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 40 mm |
| Top Tube Length | 519 mm | 534.1 mm | 555.2 mm | 565.2 mm | 575.2 mm | 595.6 mm |
| Seat Tube Angle | 75 ° | 74 ° | 73 ° | 73 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 490 mm | 520 mm | 540 mm | 560 mm | 580 mm | 610 mm |
| Head Tube Angle | 72 ° | 72 ° | 73.5 ° | 73.5 ° | 73.5 ° | 74 ° |
| Head Tube Length | 129 mm | 129 mm | 129 mm | 144 mm | 169 mm | 194 mm |
| Chainstay Length | 415 mm | 415 mm | 415 mm | 415 mm | 415 mm | 415 mm |
| Wheelbase | 981 mm | 987 mm | 981 mm | 990 mm | 1000 mm | 1005 mm |
| Bottom Bracket Drop | 69 mm | 69 mm | 69 mm | 69 mm | 69 mm | 69 mm |
| Standover Height | 757 mm | 770 mm | 781 mm | 798 mm | 820 mm | 847 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 161 cm | 166 cm | 172 cm | 178 cm | 183 cm |
| Rider Max Height | 163 cm | 169 cm | 175 cm | 181 cm | 186 cm | 191 cm |
About this model
Team is part of the Fuji Team model. Fuji launched 3 bikes of this model so far.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
General Road bikes average price
According to our math, the average price for a trustworthy General Road bike is 1915$. However, even if your budget is less than the average, you might still be able to get a top-quality General Road bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Team components
Fork material
The fork on this bike is made out of carbon, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels size
The wheels on Team are the 700c aluminum type. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Fuji Team has Rim brakes installed. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they are not nearly as effective as hydraulic brakes are.
Sizes
Fuji Team bike has 6 sizes, in the range of 155 cm – 191 cm (5.09 ft – 6.27 ft). In short, it won’t be difficult to find the right one for you.
