Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 700c -
Groupset Ultegra, 105 -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Rim
Sizing
Recommended size guide.
49cm
155cm - 163cm
52cm
161cm - 169cm
54cm
166cm - 175cm
56cm
172cm - 181cm
58cm
178cm - 186cm
61cm
183cm - 191cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Monoque C-4 carbon with custom uni-directional carbon strands, Integrated aluminum cupped head tube, Double water bottle mounts.
Suspension Fork
FC-770 Fuji Bonded Carbon Integrated w/ 1 1/8" Alloy Steerer
Drivetrain
Rear Derailleur
Shimano Ultegra
Front Derailleur
Shimano 105 F-Type
Shift Levers
Shimano 105 shifter/brake, 20-speed Flight Deck compatible
Cassette
Shimano 105, 11-25T 10-speed
Crank
FSA Gossamer MegaExo, w/Integrated spindle, 7075 CNC 34/50T Chainrings
Bottom Bracket
FSA MegaEXO Exterior Bearing System
Chain
KMC DX-10, 10sp
Pedals
none
Wheels
Rims
Shimano R-500
Tires
Continental UltraSport, 700 x 23c
Brakes
Brakes
Shimano BR-R560 dual pivot w/ cartridge pads
Brake Levers
Shimano 105 STI
Cockpit
Stem
Fuji PRO Alloy 3D forged, +/-7 degree
Handlebar
Fuji UltraLite 6061 Double Butted, 31.8mm w/Anatomical drops
Headset
Cane Creek 1 1/8" Integrated, w/ Convex hollow alloy spacer
Seat
Saddle
NEW San Marco Ponza w/Embossed logo and cro-mo rails
Seatpost
Fuji PRO Alloy, 350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 49cm | 52cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.4 mm | 1.37 mm | 1.39 mm | 1.47 mm | 1.48 mm |
| Bottom Bracket Height | 267 mm | 267 mm | 267 mm | 267 mm | 267 mm | 267 mm |
| Front Center | 577 mm | 577 mm | 576 mm | 586 mm | 596 mm | 600 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 40 mm |
| Trail | 63.3 mm | 63.3 mm | 53.8 mm | 53.8 mm | 53.7 mm | 55.9 mm |
| Stack | 532.9 mm | 532.9 mm | 537.8 mm | 552 mm | 584 mm | 603 mm |
| Reach | 381 mm | 381 mm | 392.7 mm | 398 mm | 398.6 mm | 407 mm |
| Top Tube Length | 524.2 mm | 534.1 mm | 555.8 mm | 565.2 mm | 575.2 mm | 595.5 mm |
| Seat Tube Angle | 75 ° | 74 ° | 73 ° | 73 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 490 mm | 520 mm | 540 mm | 560 mm | 580 mm | 610 mm |
| Head Tube Angle | 72 ° | 72 ° | 73.5 ° | 73.5 ° | 73.5 ° | 74 ° |
| Head Tube Length | 129 mm | 129 mm | 129 mm | 144 mm | 169 mm | 194 mm |
| Chainstay Length | 415 mm | 415 mm | 415 mm | 415 mm | 415 mm | 415 mm |
| Wheelbase | 982 mm | 982 mm | 981 mm | 990 mm | 1000 mm | 1005 mm |
| Bottom Bracket Drop | 69 mm | 69 mm | 69 mm | 69 mm | 69 mm | 69 mm |
| Standover Height | 754 mm | 771 mm | 779 mm | 798 mm | 821 mm | 847 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 161 cm | 166 cm | 172 cm | 178 cm | 183 cm |
| Rider Max Height | 163 cm | 169 cm | 175 cm | 181 cm | 186 cm | 191 cm |
About this model
Team is a Fuji Team model. There are 3 bikes that carry this model name.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for General Road bikes
Our math shows that the average cost of a dependable General Road bike is 1915$. However, even if your budget is less than the average, you might still be able to get a top-quality General Road bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
General Road bikes average weight
If we make a quick analysis of the average weight of a General Road bike, we get 9 kg (19.84 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
Team weighs 8.49 kg (18.72 lbs) and is a bit lighter than the average. In short, the average General Road bike weight is 6.01% higher than this one.
Overview of components
Fork material
The fork is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
The wheels on Team are the 700c aluminum type. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Fuji Team is equipped with Rim brakes. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, they are not nearly as effective as hydraulic brakes are.
Sizes
This bike is available in 6 sizes. They vary from 155 cm – 191 cm (5.09 ft – 6.27 ft). In short, you can easily find one that suits you.
