Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 700c -
Groupset Dura-Ace -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Rim
Sizing
Recommended size guide.
49cm
155cm - 163cm
52cm
161cm - 169cm
54cm
166cm - 175cm
56cm
172cm - 181cm
58cm
178cm - 186cm
61cm
183cm - 191cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Monocoque High Modulus C-7 carbon with 12K custom weave carbon strands, Integrated aluminum cupped head tube, Double water bottle mounts.
Suspension Fork
FC-440 Fuji Carbon Monocoque Integrated 1 1/8" Carbon steerer
Drivetrain
Rear Derailleur
Shimano Dura Ace
Front Derailleur
Shimano Dura Ace F-Type
Shift Levers
Shimano Dura Ace STI shifter/brake, 20-speed Flight Deck compatible
Cassette
Shimano Dura Ace, 12-23T 10-speed,
Crank
Shimano Dura Ace w/ Integrated Spindle, 39/53T
Bottom Bracket
Shimano Exterior Bearing system
Chain
Shimano Dura Ace 10-speed
Pedals
none
Wheels
Rims
NEW Mavic Ksyrium SL-08, 700c Clincher
Tires
Vittoria Diamonte Pro 700 X 23c
Brakes
Brakes
Shimano Dura Ace dual pivot w/cartridge pads
Brake Levers
Shimano Dura Ace STI
Cockpit
Stem
Ritchey WCS 4Axis 31.8mm, +/-6 degree
Handlebar
Ritchey Carbon WCS 31.8mm
Headset
Cane Creek IS-8I 1 1/8" Integrated, w/Carbon convex topcap and InterLoc spacers
Seat
Saddle
Selle San Marco Rever
Seatpost
Ritchey Carbon WCS 300mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 49cm | 52cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Bottom Bracket Height | 271 mm | 271 mm | 271 mm | 271 mm | 271 mm | 271 mm |
| Front Center | 577 mm | 577 mm | 576 mm | 586 mm | 596 mm | 600 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 40 mm |
| Top Tube Length | 524.4 mm | 534.3 mm | 556 mm | 565.4 mm | 568.8 mm | 595.7 mm |
| Seat Tube Angle | 75 ° | 74 ° | 73 ° | 73 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 490.2 mm | 520 mm | 540 mm | 560 mm | 580 mm | 610 mm |
| Head Tube Angle | 72 ° | 72 ° | 73.5 ° | 73.5 ° | 73.5 ° | 74 ° |
| Head Tube Length | 129 mm | 129 mm | 129 mm | 144 mm | 169 mm | 194 mm |
| Chainstay Length | 415 mm | 415 mm | 415 mm | 415 mm | 415 mm | 415 mm |
| Wheelbase | 982 mm | 982 mm | 981 mm | 991 mm | 1000 mm | 1005 mm |
| Bottom Bracket Drop | 69 mm | 69 mm | 69 mm | 69 mm | 69 mm | 69 mm |
| Standover Height | 754 mm | 771 mm | 779 mm | 798 mm | 821 mm | 847 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 161 cm | 166 cm | 172 cm | 178 cm | 183 cm |
| Rider Max Height | 163 cm | 169 cm | 175 cm | 181 cm | 186 cm | 191 cm |
Model Overview
Team Issue is part of the Fuji Team Issue model. Fuji launched 11 bikes of this model so far.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
General Road bikes average price
If you want an acceptable General Road bike you should know that the average price is 1915$. However, even if your budget is less than the average, you might still be able to get a top-quality General Road bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Average weight for General Road bikes
On a deeper look, we notice that the average weight of a General Road bike is 9 kg (19.84 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
Team Issue weighs 7.2 kg (15.87 lbs) and is much lighter than the average. In other words, this model is 25% lighter than the average General Road bike.
Team Issue components
Fork material
Team Issue has a carbon fork, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels size
The wheels on Team Issue are the 700c aluminum type. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Fuji Team Issue has Rim brakes installed. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they are not nearly as effective as hydraulic brakes are.
Sizes
Team Issue comes in 6 sizes, that range from 155 cm – 191 cm (5.09 ft – 6.27 ft). In conclusion, it won’t take much to find one that’s right for you.
