Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 650b -
Groupset Deore, Tiagra -
Suspension Rigid -
Drivetrain 3 × 9 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fuji Elios 2 custom butted Cro-Moly with outer butted seat tube, Double water bottle mounts
Suspension Fork
Fuji 1" Custom Tapered Cro-Moly, with Low Rider mounts
Drivetrain
Rear Derailleur
Shimano Deore
Front Derailleur
NEW Shimano Tiagra, 28.6mm for triple
Shift Levers
NEW Shimano Tiagra Shifter/Brake, 27-speed Flight Deck compatible
Cassette
SRAM PG-950, 11-32T 9-speed
Crank
Truvativ Touro 3.1 Alloy, 30/42/52T Chainring w/AL Outer Ring
Bottom Bracket
Sealed Cartridge Bearing
Chain
KMC-Z9000
Pedals
Wellgo Alloy Road w/clips and straps
Wheels
Front Hub
Fuji Sealed Alloy Road, 36H
Rear Hub
Fuji Sealed Alloy Body and Cassette, 36H
Rims
Fuji Double Wall Aluminum, 36H, Black CNC sidewall
Spokes
14G Stainless Steel
Tires
Kenda Eurotrek, 700 x 32c
Brakes
Brakes
Tektro Oryx canti
Brake Levers
Tektro RL-570 Cross Top Mount
Cockpit
Stem
Fuji Superlight Road Aluminum, 0 Degree, Removable Clamp
Handlebar
Fuji 6061 Butted Road, Anatomical Drops
Headset
FSA Alloy Road W/Roller Bearing
Seat
Saddle
Fuji Road Sport Anatomical Saddle with Cro-Moly Rails
Seatpost
Fuji Superlite Micro Adjust alloy, 250mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 43.2cm | 48.2cm | 53.3cm | 56cm | 58.4cm | 63.5cm |
|---|---|---|---|---|---|---|
| Bottom Bracket Height | 260 mm | 260 mm | 260 mm | 260 mm | 260 mm | 260 mm |
| Front Center | 623 mm | 615 mm | 625 mm | 622 mm | 637 mm | 632 mm |
| Rake | 60 mm | 60 mm | 60 mm | 50 mm | 55 mm | 50 mm |
| Top Tube Length | 532.9 mm | 542.7 mm | 552.2 mm | 563 mm | 576.7 mm | 586.6 mm |
| Seat Tube Angle | 74 ° | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 432 mm | 482 mm | 533 mm | 560 mm | 584 mm | 635 mm |
| Head Tube Angle | 69.9 ° | 70 ° | 70 ° | 71 ° | 71 ° | 72 ° |
| Head Tube Length | 100 mm | 100 mm | 120 mm | 140 mm | 160 mm | 165 mm |
| Chainstay Length | 438 mm | 438 mm | 438 mm | 438 mm | 438 mm | 438 mm |
| Wheelbase | 1048 mm | 1040 mm | 1050 mm | 1047 mm | 1062 mm | 1057 mm |
| Bottom Bracket Drop | 80 mm | 80 mm | 80 mm | 80 mm | 80 mm | 80 mm |
| Standover Height | 718 mm | 743 mm | 777 mm | 801 mm | 822 mm | 852 mm |
| Wheels | 650 | 650 | 650 | 650 | 650 | 650 |
About this model
Touring is a Fuji Touring model. Fuji released 25 bikes variations of this model so far.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Touring bikes
According to our math, the average price for a trustworthy Touring bike is 1007$. However, even if your budget is less than the average, you might still be able to get a top-quality Touring bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Touring bikes average weight
On a deeper look, we notice that the average weight of a Touring bike is 13.35 kg (29.43 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
Weighing 12.4 kg (27.34 lbs), the Touring model is a bit lighter than average. In other words, this model is 7.66% lighter than the average Touring bike.
Touring components
Fork material
When it comes to the fork, this bike has a steel one, which tends to be more flexible than carbon forks in general. However, a carbon fork is considerably lighter.
Wheels size
When it comes to wheels, the Touring bike is equipped with the aluminum model. After 700c wheels, 650b is the second most popular choice for road bikes. However, if you want higher speeds, you should look for a bike with 700c wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Rim brakes. Rim brakes deliver an average performance overall. However, they have problems in wet conditions.
