Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Wheels 700c -
Groupset Deore, Altus -
Suspension Rigid -
Drivetrain 3 × 9 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Custom Elios 2
Suspension Fork
Elios 2, lowrider mounts
Drivetrain
Rear Derailleur
Shimano Deore, 9-speed
Front Derailleur
Shimano Altus
Shift Levers
MicroShift, Bar end, index shifting, 9-speed
Cassette
Shimano Deore, 11-34T, 9-speed
Crank
Shimano Deore, 48/36/26T
Bottom Bracket
Sealed bearing
Chain
KMC X9 w/ MissingLink, 9-speed
Pedals
Alloy platform
Wheels
Rims
Vera Terra DPM18 rims 32h, alloy hubs, black spokes
Tires
Vera CityWide, 700 x 32c, 30 tpi
Brakes
Brakes
Tektro, linear pull, alloy
Brake Levers
Alloy, road levers
Cockpit
Stem
Oval Concepts 313, 6061 3D-forged alloy, 31.8mm, +/- 12°
Handlebar
Oval Concepts 307, 6061 alloy, 31.8mm
Headset
FSA, 1 1/8", caged bearings
Seat
Saddle
Oval Concepts P300 w/ steel rails
Seatpost
Oval Concepts 300, 3D-forged 6061 alloy, 27.2mm, double-bolt micro-adjust
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | MD | MD/LG | LG | XXL |
|---|---|---|---|---|---|
| Bottom Bracket Height | 268.5 mm | 268.5 mm | 268.5 mm | 268.5 mm | 268.5 mm |
| Top Tube Length | 550 mm | 559 mm | 570 mm | 583 mm | 593.7 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 490 mm | 540 mm | 560 mm | 580 mm | 640 mm |
| Head Tube Angle | 70 ° | 70 ° | 71 ° | 71 ° | 72 ° |
| Head Tube Length | 100 mm | 120 mm | 140 mm | 160 mm | 165 mm |
| Chainstay Length | 445 mm | 445 mm | 445 mm | 445 mm | 445 mm |
| Wheelbase | 1047 mm | 1058 mm | 1055 mm | 1069 mm | 1064 mm |
| Bottom Bracket Drop | 67 mm | 67 mm | 67 mm | 67 mm | 67 mm |
| Standover Height | 763 mm | 797 mm | 817 mm | 836 mm | 870 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
Touring completes the Fuji Touring model. There are 25 bikes that carry this model name.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Touring bikes
If you want an acceptable Touring bike you should know that the average price is 1007$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Touring bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Touring components
Fork material
Touring has a carbon fork, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
As for the wheels, Fuji Touring 2014, has a 700c aluminum model. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Fuji Touring is equipped with Rim brakes. Rim brakes deliver an average performance overall. However, they have problems in wet conditions.
