Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 700c -
Groupset Deore, Tiagra -
Suspension Rigid -
Drivetrain 3 × 9 -
Brakes Rim
Sizing
Recommended size guide.
XS
155cm - 168cm
SM
163cm - 174cm
MD
170cm - 181cm
MD/LG
175cm - 187cm
LG
181cm - 193cm
XL
188cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fuji Elios 2 custom butted Cro-Moly with outer butted seat tube, Double water bottle mounts
Suspension Fork
Fuji 1" Custom Tapered Cro-Moly, with Low Rider mounts
Drivetrain
Rear Derailleur
Shimano Deore, Top Normal
Front Derailleur
Shimano Non-series FD-R453
Shift Levers
Shimano Tiagra Integrated shifter/brake lever
Cassette
Shimano CS-HG50, 11-34T 9-speed
Crank
Shimano Sora Hollowtech design, 30,39,50T
Bottom Bracket
Shimano included w/crank
Chain
KMC Z9000
Pedals
FPD Alloy Road w/clips and straps
Wheels
Front Hub
Fuji Sealed Alloy Road, 36H
Rear Hub
Fuji Sealed Alloy Body and Cassette, 36H
Rims
Fuji Double Wall Aluminum, 36H, Black CNC sidewall
Spokes
14G Stainless Steel
Tires
Vittoria- Adventure Touring, 700 x 32c
Brakes
Brakes
Tektro Oryx Mini Canti
Brake Levers
Tektro RL-570 Cross Top Mount
Cockpit
Stem
Fuji Superlight Road Aluminum, 0 Degree, Removable Clamp
Handlebar
Fuji 6061 Butted Road, Anatomical Drops
Headset
Fuji 1" Threaded Alloy Road W/Roller Bearing
Seat
Saddle
Fuji Road Sport Anatomical Saddle
Seatpost
Fuji Superlite Micro Adjust alloy, 250mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | MD/LG | LG | XL |
|---|---|---|---|---|---|---|
| Rake | 60 mm | 60 mm | 60 mm | 55 mm | 55 mm | 50 mm |
| Top Tube Length | 530.9 mm | 540.7 mm | 550.2 mm | 561 mm | 574.7 mm | 584.7 mm |
| Seat Tube Angle | 74 ° | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 430 mm | 490 mm | 540 mm | 560 mm | 580 mm | 640 mm |
| Head Tube Angle | 69 ° | 70 ° | 70 ° | 71 ° | 71 ° | 72 ° |
| Head Tube Length | 100 mm | 100 mm | 120 mm | 140 mm | 160 mm | 165 mm |
| Chainstay Length | 436 mm | 436 mm | 436 mm | 436 mm | 436 mm | 436 mm |
| Wheelbase | 1046 mm | 1038 mm | 1048 mm | 1045 mm | 1060 mm | 1055 mm |
| Standover Height | 724 mm | 753 mm | 787 mm | 808 mm | 827 mm | 861 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 163 cm | 170 cm | 175 cm | 181 cm | 188 cm |
| Rider Max Height | 168 cm | 174 cm | 181 cm | 187 cm | 193 cm | 200 cm |
About this model
TOURING (USA) is part of the Fuji Touring model. Fuji released 25 bikes variations of this model so far.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Touring bikes
If you want to purchase a solid Touring bike, it is important to know that the average cost is 1007$. However, even if your budget is less than the average, you might still be able to get a top-quality Touring bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Average weight for Touring bikes
If we make a quick analysis of the average weight of a Touring bike, we get 13.35 kg (29.43 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
Weighing 13.15 kg (28.99 lbs), the TOURING (USA) model is slightly lighter than average. In other words, this model is 1.52% lighter than the average Touring bike.
Overview of components
Fork material
The fork on this bike is made out of steel, which tends to be more flexible than carbon forks in general. However, a carbon fork is considerably lighter.
Wheels size
The TOURING (USA) 2010 bike is equipped with 700c aluminum wheels when leaving the factory. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Fuji TOURING (USA) has Rim brakes installed. Rim brakes deliver an average performance overall. However, they have problems in wet conditions.
Sizes
There are 6 sizes available for this model. Rider height can be anywhere between 155 cm – 200 cm (5.09 ft – 6.56 ft). In conclusion, you won’t have a problem finding one that suits you.
