Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 63mm -
Fork Suntour NEX
-
Groupset Alivio, Acera -
Suspension Hardtail -
Drivetrain 2 × 9 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fuji A2-SL custom-butted alloy
Suspension Fork
SR NEX suspension, hydraulic lockout, 63mm travel
Drivetrain
Rear Derailleur
Shimano Alivio shadow OR microSHIFT Marvo LT
Front Derailleur
Shimano Acera OR microSHIFT Marvo LT
Shift Levers
Shimano Altus, 2 x 9-speed OR microSHIFT Marvo LT Xpress Shift
Cassette
Shimano Acera, 11-36T OR microSHIFT CS-H092
Crank
Shimano Altus, 46/30T OR Prowheel RPP-521
Bottom Bracket
Sealed cartridge bearing
Chain
KMC X9
Pedals
Resin platform
Wheels
Rims
Alex double wall rims 32h, Shimano center lock hubs, stainless spokes OR Formula 6 Bolt hubs
Tires
Kenda Drumlin, 700 x 40c, K-Shield flat protection OR Goodyear Transit Tour OR Panaracer, 700 x 38c
Brakes
Brakes
Shimano M200, hydraulic disc, 160mm rotors OR Tektro HD-T275 OR C-STAR Rush
Brake Levers
Shimano M200, hydraulic disc OR Tektro HD-T275 OR C-STAR Rush
Cockpit
Stem
3D-forged alloy, 6°
Handlebar
Alloy, 18mm rise, 6° backsweep
Grips
Velo comfort sport, lock on
Headset
1-1/8" semi-integrated
Seat
Saddle
Selle Royale Milo+
Seatpost
Alloy, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.627 mm | 1.585 mm | 1.642 mm | 1.634 mm | 1.643 mm |
| Front Center | 609 mm | 628 mm | 629 mm | 646 mm | 661 mm |
| Rake | 43.8 mm | 43.8 mm | 43.8 mm | 43.8 mm | 43.8 mm |
| Trail | 80 mm | 81 mm | 77 mm | 77 mm | 77 mm |
| Stack | 594 mm | 604 mm | 624 mm | 639 mm | 657 mm |
| Reach | 365 mm | 381 mm | 380 mm | 391 mm | 400 mm |
| Top Tube Length | 552 mm | 571 mm | 589 mm | 605 mm | 620 mm |
| Seat Tube Angle | 72.5 ° | 73 ° | 71.5 ° | 71.5 ° | 71.5 ° |
| Seat Tube Length | 380 mm | 440 mm | 482 mm | 533 mm | 560 mm |
| Head Tube Angle | 70 ° | 70 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 110 mm | 110 mm | 120 mm | 155 mm | 175 mm |
| Chainstay Length | 460 mm | 460 mm | 460 mm | 460 mm | 460 mm |
| Wheelbase | 1062 mm | 1081 mm | 1082 mm | 1099 mm | 1114 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 757 mm | 801 mm | 833 mm | 851 mm | 884 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
