Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset microSHIFT Advent -
Suspension Rigid -
Drivetrain 1 × 8 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Hydroformed S-6 LT aluminum, disc, QR10 x 170mm axle
Suspension Fork
S-6 aluminum, disc, QR10 x 135 mm axe
Drivetrain
Rear Derailleur
Microshift Acolyt, w/clutch, 8-speed
Shift Levers
Microshift xpress plus shifter
Cassette
Microshift, 11-46T, 8-speed
Crank
PW Fat specific, Narrow wide 28T
Bottom Bracket
Square taper, 100 x 150mm
Chain
KMC X8 EPT
Pedals
Nylon platform w/ pins
Wheels
Front Hub
Caribou Co. 9x135 mm, 6-bolts disc
Rear Hub
Caribou Co. 10x170 mm, cassette, 6-bolts disc
Rims
GL80 alloy, 80 mm, disc, 26’’, 32h
Spokes
14g, stainless steel
Tires
CST BFT, 26’’ x 4.0’’
Brakes
Brakes
Jieke JAK-8 mechanical disc
Brake Levers
Jieke JAK-8
Cockpit
Stem
Caribou Torngat 2, 7?
Handlebar
Caribou Torngat 2, 15 mm rise, Ø 31.8 mm, 680 mm
Grips
Foam, lock-on
Headset
semi-integrated, 1 1/8’’
Seat
Saddle
Garneau explore
Seatpost
Caribou Torngat 2, Ø31.6 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM |
|---|---|
| Stack Reach Ratio | 1.875 mm |
| Bottom Bracket Height | 273 mm |
| Front Center | 671 mm |
| Rake | 51 mm |
| Trail | 111 mm |
| Stack | 555 mm |
| Reach | 296 mm |
| Top Tube Length | 550 mm |
| Seat Tube Angle | 74.5 ° |
| Seat Tube Length | 320 mm |
| Head Tube Angle | 66 ° |
| Head Tube Length | 100 mm |
| Chainstay Length | 430 mm |
| Wheelbase | 1092 mm |
| Bottom Bracket Drop | 70 mm |
| Standover Height | 720 mm |
| Wheels | 26" |
