garneau E-Alpaca R Step 2023
2023 E-bike
Estimate price |
1,987$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset microSHIFT Mezzo, microSHIFT Advent -
Suspension Rigid -
Motor Bafang 250W 45Nm hub-drive -
Battery Bafung BT-F15 36V/ 18.2Ah (655Wh) integrated, smart BMS, CAN bus -
Drivetrain 1 × 7 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Humanity low step, mid-drive, hydroform S-6 LT aluminum, integrated battery, disc
Suspension Fork
Humanity, S-6 aluminum, disc
Drivetrain
Rear Derailleur
Microshift, Mezzo, CL, 7-speed
Shift Levers
Microshift xpress plus
Cassette
DNP, 13-34T, 7-speed
Crank
PW, 3 pcs, 44T
Bottom Bracket
Bafang SR PA051.12.S cadence sensor bb
Chain
KMC Z7 EPT, Anti-rust
Pedals
Platform
Wheels
Front Hub
Caribou co. disc, QR 9 x 100 mm
Rear Hub
Bafang H400B, 6 bolts disc
Rims
Torngat D21-700, 36h
Spokes
12/13g, stainless steel
Tires
CST Pro Brooklyn, reflective, 27.5 x 2.0
Brakes
Brakes
Jieke Jak-8, mechanical disc
Brake Levers
Jieke EL-210, w/sensor control
Cockpit
Stem
Caribou co. alloy, 45mm, 17?
Handlebar
Caribou Panache 2, 75 mm riser, Ø31.8 mm
Grips
Velo Ergo, lock-on
Headset
ZS44/28.6 | ZS44/30.0, 1 1/8''
Seat
Saddle
Selle Royal Essenza Relaxed
Seatpost
Caribou Panache 2, Ø30,9 mm
Motor & Battery
Motor
Bafang H400B 36V/250W, 45Nm, 32 km/h
Battery
Bafung BT-F15 36V/ 18.2Ah (655Wh) integrated, smart BMS, CAN bus
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM/MD | MD/LG |
|---|---|---|
| Stack Reach Ratio | 1.677 mm | 1.587 mm |
| Front Center | 646 mm | 686 mm |
| Rake | 55 mm | 55 mm |
| Trail | 75 mm | 75 mm |
| Stack | 622 mm | 641 mm |
| Reach | 371 mm | 404 mm |
| Top Tube Length | 610 mm | 650 |
| Seat Tube Angle | 69 ° | 69 ° |
| Seat Tube Length | 400 mm | 480 mm |
| Head Tube Angle | 69 ° | 69 ° |
| Head Tube Length | 190 mm | 210 mm |
| Chainstay Length | 480 mm | 480 mm |
| Wheelbase | 1117 mm | 1157 mm |
| Bottom Bracket Drop | 70 mm | 70 mm |
| Standover Height | 426 mm | 426 mm |
| Wheels | 650 | 650 |
Model Overview
E-Alpaca R Step belongs to the Garneau E E Alpaca model. 2 e-bikes variations carry this model name so far.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Hybrid e-bikes
Our math shows that the average cost of a dependable Hybrid e-bike is 2480$. However, even if your budget is less than the average, you might still be able to get a top-quality Hybrid e-bike. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
This e-bike was released in 2023 and its price was 2010$. Comparing the average cost of a Hybrid e-bike to this one, you will see that E-Alpaca R Step price is 23.38% lower.
E-Alpaca R Step components
Fork material
When it comes to the fork, this e-bike has an aluminum one, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels size
When leaving the production line, the E-Alpaca R Step model has aluminum wheels. 650b wheels make a great choice if you want to sacrifice speed for comfort. However, they don’t perform so well when you go over bumps and obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Garneau E-Alpaca R Step is equipped with Mechanical Disc brakes. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
