Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Travel Front 40mm -
Fork Zoom
-
Groupset microSHIFT M26 -
Suspension Hardtail -
Drivetrain 1 × 7 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
HTS steel
Suspension Fork
Zoom 565 suspension, 40 mm travel
Drivetrain
Rear Derailleur
Microshift M26CS, 7-speed
Front Derailleur
N/A
Shift Levers
Microshift TS71-7, Trigger
Cassette
Freewheel 14-32T, 7-speed
Crank
Aluminum,3-pcs, 28T
Bottom Bracket
Tange Square taper, 68 x 118 mm
Chain
KMC Z7
Pedals
Platform
Wheels
Front Hub
KT,QR 9 x 100 mm
Rear Hub
KT, freewheel, QR 10 x 135 mm
Rims
Aluminum, 20'', 28h
Spokes
14g, stainless steel
Tires
20 x 2,1''
Brakes
Brakes
Aluminum V-brake
Brake Levers
Junior specific, aluminum/resin
Cockpit
Stem
Aluminum, AheadSet, 40 mm, 7°
Handlebar
Aluminum, 40 mm rise, Ø25.4 mm
Grips
Garneau Junior
Headset
EC34 /28.6 | EC34 /30.0, 1 1/8'' threadless
Seat
Saddle
Garneau Junior
Seatpost
Aluminum, 1-bolt, Ø25.4 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM |
|---|---|
| Stack Reach Ratio | 1.736 mm |
| Front Center | 457 mm |
| Rake | 40 mm |
| Trail | 60 mm |
| Stack | 434 mm |
| Reach | 250 mm |
| Top Tube Length | 395 mm |
| Seat Tube Angle | 71.5 ° |
| Seat Tube Length | 240 mm |
| Head Tube Angle | 68 ° |
| Head Tube Length | 90 mm |
| Chainstay Length | 350 mm |
| Wheelbase | 805 mm |
| Bottom Bracket Drop | 30 mm |
| Standover Height | 503 mm |
| Front Travel | 40 mm |
| Wheels | 20" |
