Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Alivio, Acera -
Suspension Rigid -
Drivetrain 2 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Hydroformed S-6 LT aluminum, disc
Suspension Fork
Garneau, carbon, aluminum steerer, disc
Drivetrain
Rear Derailleur
Shimano Alivio M3100 shadow
Front Derailleur
Shimano Acera T3000
Shift Levers
Shimano Altus M3100, Rapidfire plus
Cassette
Shimano HG200, 11-36T 9-speed
Crank
Prowheel RPP-521, 46/30T
Bottom Bracket
Prowheel PW-BB68, external bearings
Chain
KMC Z99
Pedals
Platform
Wheels
Front Hub
Shimano, center lock disc
Rear Hub
Shimano, cassette, center lock disc
Rims
Panache D19, 32h
Spokes
14g, stainless steel
Tires
CST Sensamo, reflective, 700 x 35c
Brakes
Brakes
Power DS-100H, hydraulic disc
Brake Levers
Power
Cockpit
Stem
Caribou Panache 2, 7?
Handlebar
Caribou Panache 2, 15 mm riser, Ø31.8 mm
Grips
Velo Ergo, lock-on
Headset
Neco, 1 1/8''
Seat
Saddle
Royal Essenza + Athletic
Seatpost
Caribou Panache 2, Ø27.2 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.421 mm | 1.446 mm | 1.472 mm | 1.513 mm |
| Front Center | 614 mm | 633 mm | 647 mm | 665 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 70 mm | 70 mm | 67 mm | 67 mm |
| Stack | 550 mm | 574 mm | 599 mm | 628 mm |
| Reach | 387 mm | 397 mm | 407 mm | 415 mm |
| Top Tube Length | 545 mm | 567 mm | 590 mm | 613 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 435 mm | 470 mm | 505 mm | 540 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 71 ° | 71 ° |
| Head Tube Length | 125 mm | 150 mm | 180 mm | 210 mm |
| Chainstay Length | 450 mm | 450 mm | 450 mm | 450 mm |
| Wheelbase | 1055 mm | 1074 mm | 1089 mm | 1107 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 65 mm | 65 mm |
| Standover Height | 741 mm | 768 mm | 802 mm | 830 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
