Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 170mm -
Travel Rear 160mm -
Fork RockShox Domain
-
Groupset Deore -
Suspension Full -
Motor Yamaha 250W 85Nm mid-drive -
Battery Simplo, 720 Wh, 36 V -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
29", Alloy 6061, Integrated battery, Boost, 160 mm
Suspension Fork
RockShox Domain R, DebonAir, Air, 170 mm, tapered
Rear Shock
RockShox Super Deluxe Select, Air, 230x65 mm
Drivetrain
Rear Derailleur
Shimano Deore LG, RD-M5130, Shadow Plus, 10-S
Shift Levers
Shimano Deore, SL-M5130, Rapidfire Plus
Cassette
Shimano CS-LG600, 11-43 T
Crank
GASGAS, Narrow Wide, 38 T
Chain
Shimano CN-LG500
Chain Guide
ISCG-05
Pedals
GASGAS, aluminum
Wheels
Rims
Front: Rim: Ryde Disc30, With eyelets, Tubeless ready / Hub: GASGAS DA210F, 6-hole, 15x110 mm, thru axle, Rear: Rim: Ryde Disc30, With eyelets, Tubeless ready / Hub: GASGAS DA210R, 6-hole, 12x148 mm, thru axle
Tires
Rear: Pirelli Scorpion Enduro R, 60-622, 29 x 2.4, Tubeless ready
Brakes
Brakes
Front: SRAM DB8, 4-piston, Hydraulic disc brake, Rear: SRAM DB8, 4-piston, Hydraulic disc brake
Cockpit
Stem
GASGAS 35, 0 °, Ahead
Handlebar
GASGAS Riser 35 mm, 780 mm, Sweep: 9 °, Rise: 20 mm
Grips
GASGAS MTB, Lock-on grips
Headset
FSA Orbit ZS56/ZS56
Seat
Saddle
GASGAS MTB
Seatpost
GASGAS, 34.9 mm, Dropper post
Motor & Battery
Motor
Yamaha PW-X3, 250 W, 85 Nm
Battery
Simplo, 720 Wh, 36 V
Charger
Simplo rapid charger, 4 A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.393 mm | 1.359 mm | 1.297 mm |
| Bottom Bracket Height | 352.5 mm | 352.5 mm | 352.5 mm |
| Front Center | 782 mm | 799 mm | 826 mm |
| Rake | 44 mm | 44 mm | 44 mm |
| Trail | 139 mm | 139 mm | 139 mm |
| Stack | 620 mm | 625 mm | 629 mm |
| Reach | 445 mm | 460 mm | 485 mm |
| Top Tube Length | 576 mm | 592 mm | 619 mm |
| Seat Tube Angle | 72 ° | 72 ° | 72 ° |
| Seat Tube Length | 410 mm | 440 mm | 460 mm |
| Head Tube Angle | 64 ° | 64 ° | 64 ° |
| Head Tube Length | 100 mm | 105 mm | 110 mm |
| Chainstay Length | 460 mm | 460 mm | 460 mm |
| Wheelbase | 1241 mm | 1258 mm | 1285 mm |
| Bottom Bracket Drop | 20 mm | 20 mm | 20 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
