Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 170mm -
Travel Rear 160mm -
Fork Fox Factory Float 38
-
Groupset GX Eagle -
Suspension Full -
Motor Yamaha 250W 85Nm mid-drive -
Battery Simplo, 720 Wh, 36 V -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
29", Alloy 6061, Integrated battery, Boost, 160 mm
Suspension Fork
FOX Float 38 Factory, Grip 2, E-Optimized, Air, 170 mm, tapered
Rear Shock
FOX Float X Factory, Air, 230x65 mm
Drivetrain
Rear Derailleur
SRAM GX Eagle, 12-S
Shift Levers
SRAM GX Eagle, Single Click
Cassette
SRAM PG-1230, 11-50 T
Crank
SRAM X-Sync Eagle, 38 T
Chain
SRAM GX Eagle
Chain Guide
ISCG-05
Pedals
GASGAS, aluminum
Wheels
Rims
NEWMEN Evolution A.30, Tubeless ready, Center lock, 15x110/12x148 mm, thru axle
Tires
Rear: Schwalbe Hans Dampf, Evolution, 60-622, 29 x 2.35, Tubeless ready
Brakes
Brakes
Front: SRAM Code R, 4-piston, Hydraulic disc brake, Rear: SRAM Code R, 4-piston, Hydraulic disc brake
Cockpit
Stem
GASGAS 35, 0 °, Ahead
Handlebar
GASGAS Riser 35 mm, 780 mm, Sweep: 9 °, Rise: 20 mm
Grips
GASGAS MTB, Lock-on grips
Headset
FSA Orbit ZS56/ZS56
Seat
Saddle
GASGAS MTB
Seatpost
GASGAS, 34.9 mm, Dropper post
Motor & Battery
Motor
Yamaha PW-X3, 250 W, 85 Nm
Battery
Simplo, 720 Wh, 36 V
Charger
Simplo rapid charger, 4 A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.393 mm | 1.359 mm | 1.297 mm | 1.243 mm |
| Bottom Bracket Height | 352.5 mm | 352.5 mm | 352.5 mm | 352.5 mm |
| Front Center | 782 mm | 799 mm | 826 mm | 854 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 139 mm | 139 mm | 139 mm | 138 mm |
| Stack | 620 mm | 625 mm | 629 mm | 634 mm |
| Reach | 445 mm | 460 mm | 485 mm | 510 mm |
| Top Tube Length | 506 mm | 530 mm | 561 mm | 645 mm |
| Seat Tube Angle | 72 ° | 72 ° | 72 ° | 72 ° |
| Seat Tube Length | 410 mm | 440 mm | 460 mm | 490 mm |
| Head Tube Angle | 64 ° | 64 ° | 64 ° | 64 ° |
| Head Tube Length | 100 mm | 105 mm | 110 mm | 115 mm |
| Chainstay Length | 460 mm | 460 mm | 460 mm | 460 mm |
| Wheelbase | 1241 mm | 1258 mm | 1285 mm | 1313 mm |
| Bottom Bracket Drop | 20 mm | 20 mm | 20 mm | 20 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
