Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Travel Front 170mm -
Travel Rear 160mm -
Fork RockShox ZEB Select
-
Groupset S1000 Eagle Transmission -
Suspension Full -
Motor SRAM 250W 90Nm hub-drive -
Battery SRAM Eagle Powertrain, 630 Wh -
Drivetrain 1 × 12 Electronic -
Brakes SRAM DB8 Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
SM
158cm - 170cm
MD
168cm - 179cm
MD
168cm - 179cm
LG
176cm - 187cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
29", Carbon, Integrated battery, Boost, 160 mm
Suspension Fork
RockShox ZEB Select, DebonAir, Air, 170 mm, tapered
Rear Shock
RockShox Vivid Coil Select, Coil, 205x65 mm
Drivetrain
Rear Derailleur
SRAM S1000 Eagle Transmission, 12-S
Shift Levers
SRAM AXS Pod Controller
Cassette
SRAM XS-1270, 10-52 T
Crank
SRAM Eagle Transmission, 36 T
Chain
SRAM GX Eagle Transmission Flattop
Chain Guide
Direct Mount
Pedals
GASGAS, aluminum
Wheels
Rims
Front: Rim: Mach 1 TRUCKY 30, With eyelets, Tubeless ready / Hub: GASGAS DA210F, 6-hole, 15x110 mm, thru axle, Rear: Rim: Mach 1 TRUCKY 30, With eyelets, Tubeless ready / Hub: GASGAS DA210R, 6-hole, 12x148 mm, thru axle
Tires
Rear: Maxxis Minion DHR II, 62-622, 29 x 2.4
Brakes
Brakes
Front: SRAM DB8, 4-piston, Hydraulic disc brake, Rear: SRAM DB8, 4-piston, Hydraulic disc brake
Cockpit
Stem
Syntace Superforce 3.5, 6 °, Ahead
Handlebar
Syntace AL 6061 Advanced 31.8 mm, 780 mm, Sweep: 8 °, Rise: 20 mm
Grips
GASGAS MTB, Lock-on grips
Headset
Acros AZX-579 ZS56/ZS56
Seat
Saddle
Selle San Marco GND
Seatpost
GASGAS Pro, 34.9 mm, 402 mm, Dropper post
Motor & Battery
Motor
SRAM Eagle Powertrain Drive Unit, 250 W, 90 Nm
Battery
SRAM Eagle Powertrain, 630 Wh
Charger
SRAM Eagle Powertrain Charger, 4 A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | SM | MD | MD | LG | LG |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.442 mm | 1.442 mm | 1.396 mm | 1.396 mm | 1.352 mm | 1.352 mm |
| Bottom Bracket Height | 343 mm | 343 mm | 343 mm | 343 mm | 343 mm | 343 mm |
| Front Center | 799 mm | 799 mm | 831 mm | 831 mm | 863 mm | 863 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 135 mm | 135 mm | 136 mm | 136 mm | 135 mm | 135 mm |
| Stack | 649 mm | 649 mm | 663 mm | 663 mm | 676 mm | 676 mm |
| Reach | 450 mm | 450 mm | 475 mm | 475 mm | 500 mm | 500 mm |
| Top Tube Length | 588 mm | 588 mm | 613 mm | 613 mm | 638 mm | 638 mm |
| Seat Tube Angle | 76 ° | 76 ° | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 400 mm | 400 mm | 440 mm | 440 mm | 470 mm | 470 mm |
| Head Tube Angle | 64 ° | 64 ° | 64 ° | 64 ° | 64 ° | 64 ° |
| Head Tube Length | 115 mm | 115 mm | 130 mm | 130 mm | 145 mm | 145 mm |
| Chainstay Length | 461 mm | 461 mm | 465 mm | 465 mm | 469 mm | 469 mm |
| Wheelbase | 1258 mm | 1258 mm | 1294 mm | 1294 mm | 1330 mm | 1330 mm |
| Bottom Bracket Drop | 31 mm | 31 mm | 31 mm | 31 mm | 31 mm | 31 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 158 cm | 168 cm | 168 cm | 176 cm | 176 cm |
| Rider Max Height | 170 cm | 170 cm | 179 cm | 179 cm | 187 cm | 187 cm |
