gasgas G CROSS COUNTRY 1.0 2024
2024 E-bike
Estimate price |
2,221$
Weight | 21.9 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Travel Front 100mm -
Fork Suntour XCT
-
Groupset Tektro EDRIVE 9 -
Suspension Hardtail -
Motor Yamaha 250W 50Nm mid-drive -
Battery Yamaha DT400, 400 Wh, 36 V -
Drivetrain 1 × 8 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
27.5", Alloy 6061, External battery
Suspension Fork
SR SUNTOUR XCT30, Coil, 100 mm
Drivetrain
Rear Derailleur
Tektro RD-T350, 8-S
Shift Levers
Tektro SL-M330R
Cassette
Tektro CS-M330, 11-42 T
Crank
GASGAS, 38 T
Chain
KMC Z8
Chain Guide
Direct Mount
Pedals
GASGAS, plastic
Wheels
Rims
Front: Rim: Mach 1 TRAXX, With eyelets, Tubeless ready / Hub: GASGAS DB602F, 6-hole, 9x100 mm, Quick-release axle, Rear: Rim: Mach 1 TRAXX, With eyelets, Tubeless ready / Hub: GASGAS DB602R, 6-hole, 9x135 mm, Quick-release axle
Tires
Mitas Ocelot, 27.5, 2.35
Brakes
Brakes
Front: Tektro HD-M275, 2-piston, Hydraulic disc brake, Rear: Tektro HD-M275, 2-piston, Hydraulic disc brake
Cockpit
Stem
GASGAS 31,8, 7 °, Ahead
Handlebar
GASGAS Riser 31.8 mm, 720 mm, Sweep: 6 °, Rise: 15 mm
Grips
GASGAS MTB, Lock-on grips
Headset
GASGAS ZS44/ZS56
Seat
Saddle
GASGAS MTB
Seatpost
GASGAS, 31.6 mm, 350 mm, Patent
Motor & Battery
Motor
Yamaha PW-CE, 250 W, 50 Nm
Battery
Yamaha DT400, 400 Wh, 36 V
Charger
Yamaha rapid charger, 4 A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG |
|---|---|---|
| Stack Reach Ratio | 1.5 mm | 1.445 mm |
| Bottom Bracket Height | 320 mm | 320 mm |
| Front Center | 693 mm | 713 mm |
| Rake | 41 mm | 39 mm |
| Trail | 93 mm | 95 mm |
| Stack | 630 mm | 636 mm |
| Reach | 420 mm | 440 mm |
| Top Tube Length | 600 mm | 620 mm |
| Seat Tube Angle | 74 ° | 74 ° |
| Seat Tube Length | 450 mm | 500 mm |
| Head Tube Angle | 69 ° | 69 ° |
| Head Tube Length | 125 mm | 130 mm |
| Chainstay Length | 465 mm | 465 mm |
| Wheelbase | 1156 mm | 1176 mm |
| Bottom Bracket Drop | 35 mm | 35 mm |
| Wheels | 27" | 27" |
