Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 150mm -
Travel Rear 140mm -
Fork RockShox Domain
-
Groupset Tektro -
Suspension Full -
Motor Yamaha 250W 85Nm mid-drive -
Battery Simplo, 720 Wh, 36 V -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
29", Alloy 6061, Integrated battery, Boost, 140 mm
Suspension Fork
RockShox Domain R, DebonAir, Air, 150 mm, tapered
Rear Shock
RockShox Super Deluxe Select, Air, 230x57.5 mm
Drivetrain
Rear Derailleur
Tektro RD-M5100, 10-S
Shift Levers
Tektro SL-M5000
Cassette
Tektro CS-M5000, 11-50 T
Crank
GASGAS, Narrow Wide, 38 T
Chain
KMC e10S
Chain Guide
ISCG-05
Pedals
GASGAS, aluminum
Wheels
Rims
Front: Rim: Mach 1 TRUCKY 30, With eyelets, Tubeless ready / Hub: GASGAS DA210F, 6-hole, 15x110 mm, thru axle, Rear: Rim: Mach 1 TRUCKY 30, With eyelets, Tubeless ready / Hub: GASGAS DA210R, 6-hole, 12x148 mm, thru axle
Tires
Continental Trail King, 60-622, 29, 2.4
Brakes
Brakes
Front: SRAM DB8, 4-piston, Hydraulic disc brake, Rear: SRAM DB8, 4-piston, Hydraulic disc brake
Cockpit
Stem
GASGAS 35, 0 °, Ahead
Handlebar
GASGAS Riser 35 mm, 780 mm, Sweep: 9 °, Rise: 20 mm
Grips
GASGAS MTB, Lock-on grips
Headset
FSA Orbit ZS56/ZS56
Seat
Saddle
GASGAS MTB
Seatpost
GASGAS, 34.9 mm, Dropper post
Motor & Battery
Motor
Yamaha PW-X3, 250 W, 85 Nm
Battery
Simplo, 720 Wh, 36 V
Charger
Simplo rapid charger, 4 A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.463 mm | 1.409 mm | 1.343 mm | 1.286 mm |
| Bottom Bracket Height | 340.5 mm | 340.5 mm | 340.5 mm | 340.5 mm |
| Front Center | 753 mm | 775 mm | 802 mm | 829 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 130 mm | 132 mm | 132 mm | 132 mm |
| Stack | 629 mm | 634 mm | 638 mm | 643 mm |
| Reach | 430 mm | 450 mm | 475 mm | 500 mm |
| Top Tube Length | 564 mm | 585 mm | 611 mm | 638 mm |
| Seat Tube Angle | 72 ° | 72 ° | 72 ° | 72 ° |
| Seat Tube Length | 400 mm | 440 mm | 470 mm | 500 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 110 mm | 115 mm | 120 mm | 125 mm |
| Chainstay Length | 460 mm | 460 mm | 460 mm | 460 mm |
| Wheelbase | 1211 mm | 1233 mm | 1260 mm | 1287 mm |
| Bottom Bracket Drop | 32 mm | 32 mm | 32 mm | 32 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
