gasgas TRA 5 2024
2024 E-bike
Estimate price |
3,702$
Weight | 24.7 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 130mm -
Travel Rear 130mm -
Fork Suntour XCM
-
Groupset Tektro EDRIVE 9 -
Suspension Full -
Motor Yamaha 250W 60Nm mid-drive -
Battery Yamaha ML500, 500 Wh, 36 V -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
29", Alloy 6061, Integrated battery, Boost, 130 mm
Suspension Fork
SR SUNTOUR XCM34 Boost LO, Coil, 130 mm, tapered
Rear Shock
SR SUNTOUR Raidon R, Air, 210x55 mm
Drivetrain
Rear Derailleur
Tektro RD-M350, 9-S
Shift Levers
Tektro SL-M350R
Cassette
Tektro CS-M350, 11-46 T
Crank
GASGAS, 38 T
Chain
KMC e9S
Chain Guide
Direct Mount
Pedals
GASGAS, aluminum
Wheels
Rims
Front: Rim: Mach 1 650E, With eyelets, Tubeless ready / Hub: GASGAS DA210F, 6-hole, 15x110 mm, thru axle, Rear: Rim: Mach 1 650E, With eyelets, Tubeless ready / Hub: GASGAS DA210R, 6-hole, 12x148 mm, thru axle
Tires
Continental Cross King, 58-622, 29, 2.3
Brakes
Brakes
Front: Tektro HD-M280, 2-piston, Hydraulic disc brake, Rear: Tektro HD-M280, 2-piston, Hydraulic disc brake
Cockpit
Stem
GASGAS 31,8, 7 °, Ahead
Handlebar
GASGAS Riser 31.8 mm, 780 mm, Sweep: 6 °, Rise: 15 mm
Grips
GASGAS MTB, Lock-on grips
Headset
GASGAS ZS44/ZS56
Seat
Saddle
GASGAS MTB
Seatpost
GASGAS, 31.6 mm, 350 mm, Patent
Motor & Battery
Motor
Yamaha PW-TE, 250 W, 60 Nm
Battery
Yamaha ML500, 500 Wh, 36 V
Charger
Yamaha rapid charger, 4 A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.414 mm | 1.359 mm | 1.294 mm |
| Bottom Bracket Height | 341 mm | 341 mm | 341 mm |
| Front Center | 750 mm | 779 mm | 813 mm |
| Rake | 51 mm | 51 mm | 51 mm |
| Trail | 111 mm | 111 mm | 111 mm |
| Stack | 615 mm | 625 mm | 634 mm |
| Reach | 435 mm | 460 mm | 490 mm |
| Top Tube Length | 572 mm | 599 mm | 630 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 420 mm | 460 mm | 500 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 115 mm | 125 mm | 135 mm |
| Chainstay Length | 475 mm | 475 mm | 475 mm |
| Wheelbase | 1223 mm | 1252 mm | 1286 mm |
| Bottom Bracket Drop | 35 mm | 35 mm | 35 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
