Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Travel Front 150mm -
Travel Rear 150mm -
Fork Fox Rhythm Float 36
-
Groupset GX Eagle, NX Eagle -
Suspension Full -
Motor Yamaha 250W 70Nm mid-drive -
Battery Simplo, 630 Wh, 36 V -
Drivetrain 1 × 12 -
Brakes Shimano Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
29", Carbon/Alloy 6061, Integrated battery, Boost, 150 mm
Suspension Fork
FOX Float 36 Rhythm, Grip, Air, 150 mm, tapered
Rear Shock
FOX Float DPS Performance, Air, 230x65 mm
Drivetrain
Rear Derailleur
SRAM NX Eagle, 12-S
Shift Levers
SRAM GX Eagle, Single Click
Cassette
SRAM PG-1210, 10-50 T
Crank
SRAM X-Sync Eagle, 34 T
Chain
SRAM SX Eagle
Chain Guide
Direct Mount
Pedals
GASGAS, aluminum
Wheels
Rims
Front: Rim: Mach 1 TRUCKY 30, With eyelets, Tubeless ready / Hub: GASGAS DA210F, Center lock, 15x110 mm, thru axle, Rear: Rim: Mach 1 TRUCKY 30, With eyelets, Tubeless ready / Hub: GASGAS DA210R, Center lock, 12x148 mm, thru axle
Tires
Schwalbe Nobby Nic, Evolution, 62-622, 29 x 2.4, Tubeless ready
Brakes
Brakes
Front: Shimano BR-MT420, 4-piston, Hydraulic disc brake, Rear: Shimano BR-MT420, 4-piston, Hydraulic disc brake
Brake Levers
Shimano BL-M4100, Brake lever, adjustable, 2-finger
Cockpit
Stem
GASGAS 35, 0 °, Ahead
Handlebar
GASGAS Riser 35 mm, 780 mm, Sweep: 9 °, Rise: 20 mm
Grips
GASGAS MTB, Lock-on grips
Headset
GASGAS ZS44/ZS56
Seat
Saddle
GASGAS MTB
Seatpost
GASGAS, 31.6 mm, Dropper post
Motor & Battery
Motor
Yamaha PW-ST, 250 W, 70 Nm
Battery
Simplo, 630 Wh, 36 V
Charger
Simplo rapid charger, 4 A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.436 mm | 1.39 mm | 1.331 mm | 1.291 mm |
| Bottom Bracket Height | 346 mm | 346 mm | 346 mm | 346 mm |
| Front Center | 776 mm | 790 mm | 816 mm | 843 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 121 mm | 122 mm | 123 mm | 122 mm |
| Stack | 642 mm | 642 mm | 647 mm | 656 mm |
| Reach | 447 mm | 462 mm | 486 mm | 508 mm |
| Top Tube Length | 590 mm | 605 mm | 630 mm | 655 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 410 mm | 440 mm | 470 mm | 500 mm |
| Head Tube Angle | 65.5 ° | 65.5 ° | 65.5 ° | 65.5 ° |
| Head Tube Length | 125 mm | 125 mm | 130 mm | 140 mm |
| Chainstay Length | 475 mm | 475 mm | 475 mm | 475 mm |
| Wheelbase | 1250 mm | 1264 mm | 1290 mm | 1317 mm |
| Bottom Bracket Drop | 28 mm | 28 mm | 28 mm | 28 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
