Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Groupset GRX 800 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
164cm - 173cm
MD
170cm - 180cm
LG
177cm - 187cm
XL
184cm - 193cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Suspension Fork
Genesis CGR1 Carbon Fork With Anything Cage Mounts
Drivetrain
Rear Derailleur
Shimano GRX RD-RX810 Medium Cage
Front Derailleur
Shimano GRX FD-RX810
Shift Levers
Shimano GRX ST-R810 11 Speed
Cassette
Shimano CS-HG800-11 11-34T
Bottom Bracket
Prowheel BB68+
Chain
KMX X11
Wheels
Front Hub
Formula Front - CL-712 / Rear - RXC-142S
Rear Hub
Formula Front - CL-712 / Rear - RXC-142S
Rims
WTB ST Light i23 TCS 2.0
Spokes
Steel 14 g
Tires
Kenda Booster 700x40c Tubeless Ready / WTB Riddler 700x40c Tubeless Ready
Brakes
Brakes
Hydraulic Disc
Brake Levers
Shimano GRX ST-R810 11 Speed
Cockpit
Stem
Genesis Alloy 31.8mm -6 deg 100 mm
Headset
PT-1770 EC34 Upper / EC34 Lower
Seat
Saddle
Genesis
Seatpost
Genesis Alloy 27.2 x 350 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.433 mm | 1.519 mm | 1.529 mm | 1.538 mm |
| Bottom Bracket Height | 276 mm | 276 mm | 276 mm | 276 mm |
| Front Center | 621 mm | 618 mm | 634 mm | 651 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 67 mm | 67 mm | 68 mm | 67 mm |
| Stack | 566 mm | 585 mm | 604 mm | 623 mm |
| Reach | 395 mm | 385 mm | 395 mm | 405 mm |
| Top Tube Length | 557 mm | 558 mm | 574 mm | 589 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 490 mm | 530 mm | 560 mm | 590 mm |
| Head Tube Angle | 71 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 115 mm | 135 mm | 155 mm | 175 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1046 mm | 1043 mm | 1059 mm | 1076 mm |
| Bottom Bracket Drop | 73 mm | 73 mm | 73 mm | 73 mm |
| Standover Height | 759 mm | 785 mm | 809 mm | 833 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 164 cm | 170 cm | 177 cm | 184 cm |
| Rider Max Height | 173 cm | 180 cm | 187 cm | 193 cm |
