Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Groupset 105 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Rim
Sizing
Recommended size guide.
XS
156cm - 165cm
SM
163cm - 173cm
MD
170cm - 180cm
LG
177cm - 187cm
XL
184cm - 193cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Suspension Fork
Genesis Steel
Drivetrain
Rear Derailleur
Shimano 105 RD-R7000-GS
Front Derailleur
Shimano 105 FD-R7000 L
Shift Levers
Shimano 105 ST-R7000 11 Speed
Cassette
Shimano CS-HG700-11 11-34T
Bottom Bracket
Shimano SM-BBR60
Chain
KMC X11
Wheels
Front Hub
KT Front - KT-G15F / Rear - KT-GTER
Rear Hub
KT Front - KT-G15F / Rear - KT-GTER
Rims
Jalco MRS24
Spokes
Steel 14 g
Tires
WTB Exposure 700 x 30c
Brakes
Brakes
Promax RC-477
Brake Levers
Shimano 105 ST-R7000 11 Speed
Cockpit
Headset
PT-1767D EC34 Upper / EC34 Lower
Seat
Saddle
Genesis
Seatpost
Genesis Alloy 27.2 x 350 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.425 mm | 1.483 mm | 1.504 mm | 1.514 mm | 1.526 mm |
| Bottom Bracket Height | 264 mm | 264 mm | 264 mm | 264 mm | 264 mm |
| Front Center | 600 mm | 600 mm | 607 mm | 622 mm | 638 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 39 mm | 47 mm | 58 mm | 58 mm | 59 mm |
| Stack | 533 mm | 556 mm | 579 mm | 598 mm | 618 mm |
| Reach | 374 mm | 375 mm | 385 mm | 395 mm | 405 mm |
| Top Tube Length | 526 mm | 542 mm | 561 mm | 579 mm | 595 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 460 mm | 490 mm | 520 mm | 540 mm | 570 mm |
| Head Tube Angle | 72 ° | 72 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 120 mm | 140 mm | 160 mm | 180 mm | 200 mm |
| Chainstay Length | 420 mm | 420 mm | 420 mm | 420 mm | 420 mm |
| Wheelbase | 1009 mm | 1009 mm | 1016 mm | 1032 mm | 1048 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm |
| Standover Height | 759 mm | 780 mm | 797 mm | 823 mm | 846 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 170 cm | 177 cm | 184 cm |
| Rider Max Height | 165 cm | 173 cm | 180 cm | 187 cm | 193 cm |
