Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Groupset Tiagra -
Suspension Rigid -
Drivetrain 3 × 10 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XS
156cm - 165cm
SM
163cm - 173cm
MD
170cm - 180cm
LG
177cm - 187cm
XL
184cm - 193cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Suspension Fork
Reynolds 725 Steel Tubing, Genesis Chromoly Fork
Drivetrain
Rear Derailleur
Shimano Tiagra RD-4700-GS Medium Cage
Front Derailleur
Shimano Tiagra FD-4703
Shift Levers
Shimano Tiagra ST-4700 3 x 10 Speed
Cassette
Shimano CS-HG500-10 11-32T
Bottom Bracket
Shimano BB-ES300
Chain
KMC X10
Pedals
NW-91K With Cage
Wheels
Front Hub
Shimano Front - DH-UR700-3D / Rear FH-M6000
Rear Hub
Shimano Front - DH-UR700-3D / Rear FH-M6000
Rims
Sun Ringle Rhyno Lite Rims, Shimano Dynamo Front Hub, QR Front & Rear, Vittoria Randonneur Tech 700 x 40mm Tyres
Spokes
Steel 14 g
Tires
Schwalbe Marathon
Brakes
Brakes
Sun Ringle Rhyno Lite Rims, Shimano Dynamo Front Hub, QR Front & Rear, Vittoria Randonneur Tech 700 x 40mm Tyres, Promax DSK-717 Mechanical Disc Brakes, 180mm Front & 160mm Rear Rotors, AtranVelo AVS Rear & Lowrider Front Racks, Busch & Muller Dynamo Light Set
Brake Levers
Shimano Tiagra ST-4700 3 x 10 Speed
Cockpit
Stem
Genesis Alloy 31.8mm -6 deg 100 mm
Headset
PT-1770 EC34 Upper / EC34 Lower
Seat
Saddle
Genesis
Seatpost
Genesis Alloy 27.2 XS/S/M = 350 mm L/XL = 400 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.489 mm | 1.526 mm | 1.546 mm | 1.555 mm | 1.563 mm |
| Bottom Bracket Height | 263 mm | 263 mm | 263 mm | 263 mm | 263 mm |
| Front Center | 617 mm | 622 mm | 630 mm | 646 mm | 662 mm |
| Rake | 55 mm | 55 mm | 55 mm | 55 mm | 55 mm |
| Trail | 61 mm | 61 mm | 54 mm | 54 mm | 54 mm |
| Stack | 566 mm | 580 mm | 603 mm | 622 mm | 641 mm |
| Reach | 380 mm | 380 mm | 390 mm | 400 mm | 410 mm |
| Top Tube Length | 543 mm | 557 mm | 569 mm | 584 mm | 600 mm |
| Seat Tube Angle | 74 ° | 73 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 470 mm | 510 mm | 540 mm | 580 mm | 600 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 71.5 ° | 71.5 ° | 71.5 ° |
| Head Tube Length | 120 mm | 135 mm | 155 mm | 175 mm | 195 mm |
| Chainstay Length | 465 mm | 465 mm | 465 mm | 465 mm | 465 mm |
| Wheelbase | 1072 mm | 1077 mm | 1085 mm | 1101 mm | 1117 mm |
| Bottom Bracket Drop | 73 mm | 73 mm | 73 mm | 73 mm | 73 mm |
| Standover Height | 754 mm | 785 mm | 811 mm | 841 mm | 859 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 170 cm | 177 cm | 184 cm |
| Rider Max Height | 165 cm | 173 cm | 180 cm | 187 cm | 193 cm |
