Ghost E-RIOT AM 30 2025
2025 E-bike
Estimate price |
12,797$
Weight | 25 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Travel Front 160mm -
Fork RockShox ZEB Ultimate
-
Groupset X0 Eagle Transmission, Eagle AXS -
Suspension Full -
Motor Bosch 600W 85Nm mid-drive -
Battery Bosch InTube 750 Wh, Capacity: 750 Wh, Location: Powertube -
Drivetrain 1 × 12 Electronic -
Brakes SRAM Code Ultimate Stealth Hydraulic Disc
Sizing
Recommended size guide.
SM
161cm - 172cm
MD
170cm - 180cm
LG
178cm - 189cm
XL
187cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
HIGH Carbon Uni
Suspension Fork
Rockshox ZEB Ultimate 160 mm
Rear Shock
Rockshox Super Deluxe Ultimate RC2T 205x65mm, Trunnion
Drivetrain
Rear Derailleur
SRAM X0 Eagle T-Type 12s
Shift Levers
SRAM AXS Pod Controller
Cassette
SRAM XS-1295 Eagle T-Type, XD
Crank
Race Face Era-E 165
Chain
SRAM X0 Eagle T-Type 12s
Chain Guide
MRP 1x
Pedals
VP VP-503
Wheels
Rims
DT Swiss HX1501 Spline One 30 mm 15x110 mm
Tires
Maxxis Minion DHF 3C MaxxTerra Exo+ 2.5
Brakes
Brakes
SRAM Hydraulic Disc brake Code Ultimate Stealth, 220 mm
Brake Levers
SRAM Code Ultimate Stealth-BL
Cockpit
Stem
Truvativ Descendant Dia. 35 mm, L: 50 mm
Handlebar
Truvativ Riser Bar Descendant Riser Carbon Downhill Dia. 35 mm
Headset
Acros Semi-integrated Blocklock 135° AZX-582
Seat
Saddle
Prologo MTB Proxim W450 Performance
Seatpost
Eightpins Dropperpost H01 Hydraulic, telescope, Dia. 34.9 mm
Motor & Battery
Motor
Bosch Performance Line CX
Battery
Bosch InTube 750 Wh, Capacity: 750 Wh, Location: Powertube
Charger
Bosch Charger 4A 220-240V
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.396 mm | 1.34 mm | 1.356 mm | 1.314 mm |
| Bottom Bracket Height | 331 mm | 336 mm | 336 mm | 336 mm |
| Front Center | 763 mm | 795 mm | 832 mm | 870 mm |
| Rake | 46 mm | 53 mm | 53 mm | 52 mm |
| Trail | 111 mm | 112 mm | 112 mm | 114 mm |
| Stack | 617 mm | 627 mm | 663 mm | 682 mm |
| Reach | 442 mm | 468 mm | 489 mm | 519 mm |
| Top Tube Length | 570 mm | 587 mm | 617 mm | 650 |
| Seat Tube Angle | 78.3 ° | 79.3 ° | 79.1 ° | 79.1 ° |
| Seat Tube Length | 417 mm | 441 mm | 465 mm | 489 mm |
| Head Tube Angle | 65.5 ° | 65.5 ° | 65.5 ° | 65.5 ° |
| Head Tube Length | 120 mm | 100 mm | 140 mm | 160 mm |
| Chainstay Length | 435 mm | 455 mm | 455 mm | 455 mm |
| Wheelbase | 1197 mm | 1248 mm | 1285 mm | 1323 mm |
| Bottom Bracket Drop | 24 mm | 38 mm | 38 mm | 38 mm |
| Standover Height | 746 mm | 740 mm | 748 mm | 751 mm |
| Wheels | 27" | 29" | 29" | 29" |
| Rider Min Height | 161 cm | 170 cm | 178 cm | 187 cm |
| Rider Max Height | 172 cm | 180 cm | 189 cm | 198 cm |
