Ghost E-Teru B Pro EQ 2024
2024 E-bike
Estimate price |
5,583$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 100mm -
Fork RockShox 35 Silver
-
Groupset XT -
Suspension Hardtail -
Motor Bosch 600W 85Nm mid-drive -
Battery Bosch Power Tube 750 Wh -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
164cm - 173cm
MD
171cm - 181cm
LG
179cm - 189cm
XL
187cm - 196cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
E-TERU AL
Suspension Fork
Rock Shox 35 Silver TK Solo Air 100 mm
Drivetrain
Rear Derailleur
Shimano XT RD-M8100 12-S
Cassette
Shimano SLX CS-M7100 10-51
Crank
Samox / FSA 38T
Chain
Shimano Deore CN-M6100
Pedals
VPE-527
Wheels
Rims
Front: WTB ST i30, Rear: WTB ST i30
Tires
Front: Schwalbe Johnny Watts 2.35, Rear: Schwalbe Johnny Watts 2.35
Brakes
Brakes
Shimano BR-MT420 203/180 mm Disc
Brake Levers
Shimano BL-M4100
Cockpit
Stem
Ground Fiftyone Dia. 31.8 mm
Handlebar
Ground Fiftyone Dia. 31.8 S: 720/20 M/L: 740/27 XL: 760/40
Grips
MTB Ergo Grip
Seat
Saddle
Selle Royal Vivo
Seatpost
GHOST SP DC1 31.6 mm
Motor & Battery
Motor
Bosch Performance Line CX
Battery
Bosch Power Tube 750 Wh
Charger
Bosch Charger 4 Ah
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.498 mm | 1.472 mm | 1.436 mm | 1.415 mm |
| Front Center | 719 mm | 744 mm | 770 mm | 799 mm |
| Rake | 51 mm | 52 mm | 50 mm | 51 mm |
| Trail | 100 mm | 98 mm | 101 mm | 100 mm |
| Stack | 614 mm | 633 mm | 646 mm | 665 mm |
| Reach | 410 mm | 430 mm | 450 mm | 470 mm |
| Top Tube Length | 586 mm | 612 mm | 635 mm | 661 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 380 mm | 430 mm | 470 mm | 510 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 110 mm | 120 mm | 140 mm | 160 mm |
| Chainstay Length | 445 mm | 455 mm | 455 mm | 455 mm |
| Wheelbase | 1159 mm | 1193 mm | 1220 mm | 1249 mm |
| Bottom Bracket Drop | 50 mm | 60 mm | 55 mm | 55 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 164 cm | 171 cm | 179 cm | 187 cm |
| Rider Max Height | 173 cm | 181 cm | 189 cm | 196 cm |
