Ghost E-Teru Pro EQ Low 2024
2024 E-bike
Estimate price |
5,234$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 100mm -
Fork RockShox 35 Silver
-
Groupset XT -
Suspension Hardtail -
Motor Bosch 600W 85Nm mid-drive -
Battery Bosch Power Tube 750 Wh -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 169cm
MD
167cm - 179cm
LG
177cm - 191cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
E-TERU AL Low
Suspension Fork
Rock Shox 35 Silver TK Solo Air 100 mm
Drivetrain
Rear Derailleur
Shimano XT RD-M8100 12-S
Cassette
Shimano SLX CS-M7100 10-51
Crank
Miranda Virage 38T
Chain
KMC e12 EPT
Pedals
VPE-527
Wheels
Rims
Front: Schürmann Yak Disc 25, Rear: Schürmann Yak Disc 25
Tires
Front: Schwalbe Johnny Watts 2.35, Rear: Schwalbe Johnny Watts 2.35
Brakes
Brakes
Shimano BR-MT420 203 mm Disc
Brake Levers
Shimano BL-M4100
Cockpit
Stem
Ground Fiftyone Adjustable Dia. 31.8 mm
Handlebar
Ground Fiftyone Dia. 31.8 mm 720/20 (S) 740/27 (M-L)
Grips
MTB Grip
Seat
Saddle
Selle Royal Vivo
Seatpost
Ghost 34.9 mm
Motor & Battery
Motor
Bosch Performance Line CX
Battery
Bosch Power Tube 750 Wh
Charger
Bosch Charger 4 Ah
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.565 mm | 1.507 mm | 1.47 mm |
| Front Center | 699 mm | 708 mm | 740 mm |
| Rake | 44 mm | 44 mm | 45 mm |
| Trail | 87 mm | 80 mm | 79 mm |
| Stack | 659 mm | 663 mm | 682 mm |
| Reach | 421 mm | 440 mm | 464 mm |
| Top Tube Length | 610 mm | 630 mm | 660 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 380 mm | 450 mm | 500 mm |
| Head Tube Angle | 69 ° | 70 ° | 70 ° |
| Head Tube Length | 150 mm | 155 mm | 175 mm |
| Chainstay Length | 475 mm | 475 mm | 475 mm |
| Wheelbase | 1167 mm | 1177 mm | 1209 mm |
| Bottom Bracket Drop | 65 mm | 60 mm | 60 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 167 cm | 177 cm |
| Rider Max Height | 169 cm | 179 cm | 191 cm |
