Ghost LECTOR ADVANCED 2025
2025 Mountain
Estimate price |
3,256$
Weight | 12 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Travel Front 110mm -
Fork RockShox SID
-
Groupset GX Eagle, NX Eagle -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Formula Cura Hydraulic Disc
Sizing
Recommended size guide.
XS
154cm - 165cm
SM
163cm - 173cm
MD
171cm - 181cm
LG
179cm - 189cm
XL
187cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Uni
Suspension Fork
Rockshox SID Base 2P Rush RL Remote, DebonAir+ 110 mm
Drivetrain
Rear Derailleur
SRAM GX Eagle 12s
Shift Levers
SRAM Triggershift NX Eagle Trigger, Matchmaker-X compatible
Cassette
SRAM PG-1230 Eagle, HG
Crank
SRAM FC GX Eagle DUB Crankset, DM
Bottom Bracket
SRAM PressFit DUB PF 92 MTB WIDE
Chain
SRAM GX Eagle 12s
Wheels
Front Hub
Shimano HB-TC500-15-B 15x110 mm, 32H, Centerlock
Rear Hub
Shimano FH-TC500-HM-B 12x148 mm, 32H, Centerlock, HG
Rims
WTB ST Light i25 29" TCS 2.0, 32H, Single eyelets
Tires
Maxxis REKON EXO/TR, Foldable, 60TPI, black 61-622
Brakes
Brakes
Formula Hydraulic Disc brake CURA 2, 2 pistons, 160 mm
Brake Levers
Formula CURA 2-BL
Cockpit
Stem
Ghost Not Adjustable Ground Fiftyone Dia. 31.8 mm, L: 45 mm, A-Head
Handlebar
Ghost Flat bar Ground Fiftyone Dia. 31.8 mm, backsweep 8°
Headset
Acros Semi-integrated IS52 ICR / ZS56 Blocklock 150°
Seat
Saddle
Selle Italia MTB SLS Sport Black
Seatpost
Kalloy Non Suspension SPF103, Dia. 31.6 mm, L: 350 mm 350 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.483 mm | 1.364 mm | 1.262 mm | 1.243 mm | 1.236 mm |
| Bottom Bracket Height | 314 mm | 314 mm | 314 mm | 319 mm | 319 mm |
| Front Center | 689 mm | 725 mm | 761 mm | 796 mm | 833 mm |
| Rake | 48 mm | 48 mm | 48 mm | 47 mm | 48 mm |
| Trail | 100 mm | 100 mm | 100 mm | 101 mm | 100 mm |
| Stack | 611 mm | 611 mm | 611 mm | 634 mm | 661 mm |
| Reach | 412 mm | 448 mm | 484 mm | 510 mm | 535 mm |
| Top Tube Length | 567 mm | 603 mm | 639 mm | 671 mm | 704 mm |
| Seat Tube Angle | 75.8 ° | 75.7 ° | 75.7 ° | 75.7 ° | 75.7 ° |
| Seat Tube Length | 405 mm | 425 mm | 445 mm | 465 mm | 485 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 90 mm | 90 mm | 90 mm | 110 mm | 140 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1112 mm | 1148 mm | 1184 mm | 1221 mm | 1258 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 55 mm | 55 mm |
| Standover Height | 759 mm | 762 mm | 767 mm | 787 mm | 795 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 154 cm | 163 cm | 171 cm | 179 cm | 187 cm |
| Rider Max Height | 165 cm | 173 cm | 181 cm | 189 cm | 198 cm |
