Ghost Nirvana Trail Universal 2024
2024 Mountain
Estimate price |
2,293$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 140mm -
Fork RockShox Recon Silver RL
-
Groupset GX Eagle, Truvativ Stylo -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
164cm - 173cm
MD
171cm - 181cm
LG
179cm - 189cm
XL
187cm - 201cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
NIRVANA AL
Suspension Fork
Rock Shox Recon Silver RL 140mm
Drivetrain
Rear Derailleur
SRAM GX Eagle 12-S
Cassette
SRAM PG-1210 11-50
Crank
Truvativ Stylo 6K 32T
Bottom Bracket
SRAM Power Spline 118/73
Chain
SRAM SX Eagle
Wheels
Rims
Front: WTB ST i25, Rear: WTB ST i25
Tires
Front: Schwalbe Nobby Nic Super Trail Addix Soft 2.4 (S 27,5"; M-XL 29"), Rear: Schwalbe Nobby Nic Super Ground Addix Speed Grip 2.4 (S 27,5"; M-XL 29")
Brakes
Brakes
Shimano BR-MT410 180 mm Disc
Brake Levers
Shimano BL-MT401
Cockpit
Stem
Ground Fiftyone Dia. 31.8 mm
Handlebar
Ground Fiftyone Race Dia. 31.8 mm 0/700 mm (XS/S) 20/720 mm (M) 27/740 mm (L) 40/760 mm (XL)
Grips
WTB Wafel
Seat
Saddle
WTB Volt
Seatpost
Eightpins hydraulic 34.9 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.447 mm | 1.463 mm | 1.465 mm | 1.418 mm |
| Bottom Bracket Height | 316 mm | 303 mm | 308 mm | 308 mm |
| Front Center | 729 mm | 761 mm | 798 mm | 834 mm |
| Rake | 46 mm | 56 mm | 56 mm | 56 mm |
| Trail | 116 mm | 105 mm | 105 mm | 105 mm |
| Stack | 618 mm | 645 mm | 677 mm | 695 mm |
| Reach | 427 mm | 441 mm | 462 mm | 490 mm |
| Top Tube Length | 580 mm | 600 mm | 629 mm | 659 mm |
| Seat Tube Angle | 76.1 ° | 76.2 ° | 76.1 ° | 76.3 ° |
| Seat Tube Length | 417 mm | 441 mm | 465 mm | 489 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 100 mm | 100 mm | 140 mm | 160 mm |
| Chainstay Length | 405 mm | 425 mm | 425 mm | 425 mm |
| Wheelbase | 1128 mm | 1177 mm | 1215 mm | 1251 mm |
| Bottom Bracket Drop | 58 mm | 71 mm | 66 mm | 66 mm |
| Standover Height | 710 mm | 728 mm | 764 mm | 784 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 164 cm | 171 cm | 179 cm | 187 cm |
| Rider Max Height | 173 cm | 181 cm | 189 cm | 201 cm |
