Ghost PATH RIOT 30 2025
2025 E-bike
Estimate price |
12,215$
Weight | 19.55 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Travel Front 160mm -
Fork RockShox ZEB Ultimate
-
Groupset X0 Eagle Transmission, Eagle AXS -
Suspension Full -
Motor Fazua 450W 60Nm mid-drive -
Battery Fazua Energy 480 Wh, Capacity: 480 Wh, Location: Powertube -
Drivetrain 1 × 12 Electronic -
Brakes SRAM Code Ultimate Stealth Hydraulic Disc
Sizing
Recommended size guide.
SM
161cm - 172cm
MD
170cm - 180cm
LG
178cm - 189cm
XL
187cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
HIGH Carbon Uni
Suspension Fork
Rockshox ZEB Ultimate 160 mm
Rear Shock
Rockshox Super Deluxe Ultimate RC2T 185x55mm, Trunnion
Drivetrain
Rear Derailleur
SRAM X0 Eagle T-Type 12s
Shift Levers
SRAM AXS Pod Controller
Cassette
SRAM XS-1295 Eagle T-Type, XD
Crank
Ghost Rotor crank set for Fazua 165
Chain
SRAM X0 Eagle T-Type 12s
Wheels
Rims
DT Swiss HXC 1501 Spline One LS 30 mm 15x110 mm
Tires
Maxxis Assegai 3C MaxxGrip Exo+ 2.5
Brakes
Brakes
SRAM Hydraulic Disc brake Code Ultimate Stealth, 220 mm
Brake Levers
SRAM Code Ultimate Stealth-BL
Cockpit
Stem
Truvativ Descendant Dia. 35 mm, L: 50 mm
Handlebar
Truvativ Riser Bar Descendant Riser Carbon Downhill Dia. 35 mm
Headset
Acros Semi-integrated Blocklock 135° AZX-582
Seat
Saddle
Prologo MTB Proxim W450 Performance
Seatpost
Eightpins Dropperpost H01 Hydraulic, telescope, Dia. 34.9 mm
Motor & Battery
Motor
Fazua Ride 60
Battery
Fazua Energy 480 Wh, Capacity: 480 Wh, Location: Powertube
Charger
Fazua Charger 3A, 230V
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.395 mm | 1.346 mm | 1.317 mm | 1.276 mm |
| Bottom Bracket Height | 340 mm | 340 mm | 344 mm | 344 mm |
| Front Center | 780 mm | 819 mm | 859 mm | 896 mm |
| Rake | 52 mm | 52 mm | 52 mm | 51 mm |
| Trail | 129 mm | 129 mm | 129 mm | 130 mm |
| Stack | 607 mm | 626 mm | 648 mm | 666 mm |
| Reach | 435 mm | 465 mm | 492 mm | 522 mm |
| Top Tube Length | 581 mm | 615 mm | 647 mm | 681 mm |
| Seat Tube Angle | 76.5 ° | 76.5 ° | 76.5 ° | 76.5 ° |
| Seat Tube Length | 417 mm | 441 mm | 465 mm | 489 mm |
| Head Tube Angle | 63.5 ° | 63.5 ° | 63.5 ° | 63.5 ° |
| Head Tube Length | 90 mm | 110 mm | 140 mm | 160 mm |
| Chainstay Length | 446 mm | 446 mm | 455 mm | 455 mm |
| Wheelbase | 1224 mm | 1263 mm | 1312 mm | 1350 mm |
| Bottom Bracket Drop | 34 mm | 34 mm | 30 mm | 30 mm |
| Standover Height | 778 mm | 792 mm | 817 mm | 835 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 161 cm | 170 cm | 178 cm | 187 cm |
| Rider Max Height | 172 cm | 180 cm | 189 cm | 198 cm |
