Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Travel Front 180mm -
Fork RockShox ZEB Select
-
Groupset Eagle 70 Transmission -
Suspension Full -
Drivetrain 1 × 12 -
Brakes SRAM Maven Bronze Hydraulic Disc
Sizing
Recommended size guide.
SM
161cm - 172cm
MD
170cm - 181cm
LG
179cm - 189cm
XL
187cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
HIGH Carbon Uni
Suspension Fork
Rockshox ZEB Select Charger RC, Boost, DebonAir+, 180 mm
Rear Shock
Rockshox Vivid Select 250x70mm, Vivid Air, Standard
Drivetrain
Rear Derailleur
SRAM Eagle 70 T-Type 12s
Shift Levers
SRAM Triggershift Eagle 70 T-Type Single Click Trigger
Cassette
SRAM XS-1270 Eagle T-Type, HG
Crank
SRAM FC Eagle 70 DUB T-Type Crankset w/ Guard, DM 165
Bottom Bracket
SRAM BSA DUB BSA 73 MTB WIDE
Chain
SRAM Eagle 70 T-Type 12s
Wheels
Front Hub
Shimano HB-TC500-15-B 15x110 mm, 32H, Centerlock
Rear Hub
Shimano FH-TC500-HM-B 12x148 mm, 32H, Centerlock, HG
Rims
WTB ST Tough TCS 2.0 27.5" Pinned 32H Vinyl
Tires
Continental Kryptotal-Fr Enduro Soft, foldable skin SL, TR 60-622
Brakes
Brakes
SRAM Hydraulic Disc brake DB Maven Bronze, 4 pistons, organic pad, 200 mm
Brake Levers
SRAM DB Maven Bronze-BL
Cockpit
Stem
PMG Not Adjustable Team All Mtn, Dia. 31.8 mm, L: 40 mm, A-Head
Handlebar
XLC Riser Bar MTB Dia. 31.8 mm, Rise: 19 mm, backsweep 9°
Headset
Acros Semi-integrated AMX-002/3 Mod56/66, reach adjustable +/-5 mm
Seat
Saddle
Prologo MTB Proxim Nembo Steel rail 145 mm
Seatpost
Tranz X Dropperpost MTB +RAD JD-YSI35, Dia. 34.9 mm, Travel: 180 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.462 mm | 1.373 mm | 1.324 mm | 1.29 mm |
| Bottom Bracket Height | 341 mm | 341 mm | 341 mm | 341 mm |
| Front Center | 785 mm | 817 mm | 847 mm | 871 mm |
| Rake | 42 mm | 41 mm | 43 mm | 42 mm |
| Trail | 127 mm | 128 mm | 126 mm | 127 mm |
| Stack | 636 mm | 640 mm | 649 mm | 658 mm |
| Reach | 435 mm | 466 mm | 490 mm | 510 mm |
| Top Tube Length | 570 mm | 603 mm | 630 mm | 652 mm |
| Seat Tube Angle | 78 ° | 78 ° | 78 ° | 78 ° |
| Seat Tube Length | 415 mm | 430 mm | 445 mm | 475 mm |
| Head Tube Angle | 64 ° | 64 ° | 64 ° | 64 ° |
| Head Tube Length | 100 mm | 105 mm | 115 mm | 125 mm |
| Chainstay Length | 439 mm | 439 mm | 444 mm | 444 mm |
| Wheelbase | 1224 mm | 1256 mm | 1291 mm | 1315 mm |
| Bottom Bracket Drop | 14 mm | 14 mm | 14 mm | 14 mm |
| Standover Height | 741 mm | 741 mm | 741 mm | 751 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 161 cm | 170 cm | 179 cm | 187 cm |
| Rider Max Height | 172 cm | 181 cm | 189 cm | 198 cm |
