Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Travel Front 180mm -
Fork Fox Factory Float 38
-
Groupset XT -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Tektro Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Uni
Suspension Fork
FOX 38 FLOAT Factory GRIP X2, Boost, 180 mm
Rear Shock
FOX FLOAT X2 Factory, 2pos-Adj. 250x70mm
Drivetrain
Rear Derailleur
Shimano Deore XT RD-M8100-SGS 12s, Shadow+
Cassette
Shimano Deore XT CS-M8100-12, MICRO SPLINE, 10-51T
Crank
Shimano Deore XT FC-M8200, HOLLOWTECH II, 30T
Bottom Bracket
Shimano Deore BB-MT501 68/73 mm, HOLLOWTECH II, BSA
Chain
Shimano Deore XT CN-M8100 12s
Chain Guide
MRP AMG SL 30T hardware 2x12 mm, 1x10 mm
Wheels
Rims
DT Swiss F 1900 29" 15x110 mm, 6 bolt Disc, TR
Tires
Front: Continental Kryptotal-Fr Enduro Soft, foldable skin SL, TR 60-622, Rear: Continental Kryptotal-Re Enduro Soft, foldable skin SL, TR 60-584
Brakes
Brakes
Tektro TRP DH-R EVO Silver Grey, 4 pistons, 220 / 203 mm
Brake Levers
Tektro TRP HD-M846 DH-R EVO Silver Grey-BL
Cockpit
Stem
Race Face Turbine R Dia. 35 mm
Handlebar
Raceface Turbine Dia. 35 mm, Rise: 20 mm, W: 800 mm
Grips
XLC GR-S34 MTB Sport Bar Grips - black
Seat
Saddle
Prologo Proxim Nembo Steel 145 mm
Seatpost
TRANZ X Dropper MTB +RAD JD-YSI35, Dia. 34.9 mm, Travel: 160 mm
