Ghost RIOT TRAIL CF FULL PARTY 2025
2025 Mountain
Estimate price |
6,397$
Weight | 15 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Travel Front 150mm -
Fork Fox Factory Float 36
-
Groupset XT, SLX -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Formula Cura 4 Hydraulic Disc
Sizing
Recommended size guide.
SM
164cm - 173cm
MD
171cm - 181cm
LG
179cm - 189cm
XL
187cm - 196cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
HIGH Carbon Uni
Suspension Fork
FOX Factory 36 FLOAT Factory FIT4 150 mm, QR
Rear Shock
FOX Factory FLOAT X Factory, 2 pos-Adj, EVOL LV, 185x55mm
Drivetrain
Rear Derailleur
Shimano Deore XT RD-M8100-SGS 12s, Shadow+
Shift Levers
Shimano Triggershift SLX SL-M7100-R, Rapidfire+
Cassette
Shimano SLX CS-M7100-12, MICRO SPLINE
Crank
Shimano FC-MT512-1, 2-Piece Crankset 170
Bottom Bracket
Shimano BSA Deore SM-BB52 68/73 mm, HOLLOWTECH II
Chain
Shimano Deore CN-M6100 12s
Wheels
Rims
DT Swiss M 1900 Spline 29"/700C 15x110 mm, 6 bolt Disc
Tires
Maxxis Assegai 3C MaxxGrip/Exo+/Foldable/TR 61-622
Brakes
Brakes
Formula Hydraulic Disc brake CURA 4, 4 pistons, 203 mm
Brake Levers
Formula CURA 4-BL
Cockpit
Stem
PMG Not Adjustable Team All Mtn, Dia. 31.8 mm, L: 50 mm, A-Head
Handlebar
PMG Riser Bar Race Alloy Riser Bar, Dia. 31.8 mm, Rise: 15 mm
Headset
Acros Semi-integrated Blocklock 135° ZS44/ZS56 Tapered
Seat
Saddle
WTB MTB Volt Medium Steel 142x265 mm
Seatpost
Eightpins Dropperpost H01 Hydraulic, telescope, Dia. 34.9 mm, 6X-S
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.37 mm | 1.321 mm | 1.296 mm | 1.256 mm |
| Bottom Bracket Height | 336 mm | 336 mm | 341 mm | 341 mm |
| Front Center | 776 mm | 815 mm | 854 mm | 893 mm |
| Rake | 52 mm | 52 mm | 52 mm | 53 mm |
| Trail | 125 mm | 125 mm | 125 mm | 124 mm |
| Stack | 604 mm | 622 mm | 644 mm | 662 mm |
| Reach | 441 mm | 471 mm | 497 mm | 527 mm |
| Top Tube Length | 580 mm | 614 mm | 646 mm | 678 mm |
| Seat Tube Angle | 77 ° | 77 ° | 77 ° | 77 ° |
| Seat Tube Length | 417 mm | 441 mm | 465 mm | 489 mm |
| Head Tube Angle | 64 ° | 64 ° | 64 ° | 64 ° |
| Head Tube Length | 90 mm | 110 mm | 140 mm | 160 mm |
| Chainstay Length | 446 mm | 446 mm | 455 mm | 455 mm |
| Wheelbase | 1219 mm | 1258 mm | 1307 mm | 1346 mm |
| Bottom Bracket Drop | 38 mm | 38 mm | 33 mm | 33 mm |
| Standover Height | 742 mm | 749 mm | 775 mm | 793 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 164 cm | 171 cm | 179 cm | 187 cm |
| Rider Max Height | 173 cm | 181 cm | 189 cm | 196 cm |
