Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 63mm -
Fork Suntour NEX
-
Groupset Alivio, Acera -
Suspension Hardtail -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
162cm - 172cm
MD
170cm - 180cm
LG
178cm - 188cm
XL
186cm - 197cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
SQUARE CROSS AL
Suspension Fork
SR Suntour NEX DS 63 mm
Drivetrain
Rear Derailleur
Shimano Alivio RD-M3100 9-S
Cassette
Shimano CS-HG400-9 11-34
Crank
Shimano FC-T3010 44-32-22
Bottom Bracket
Prestine PT-6621
Chain
KMC X9
Wheels
Rims
Front: Rodi Excalibur XC19, Rear: Rodi Excalibur XC19
Tires
Front: Schwalbe Smart Sam Performance 47-622, Rear: Schwalbe Smart Sam Performance 47-622
Brakes
Brakes
Shimano BR-MT200 160 mm Disc
Brake Levers
Shimano BL-MT200
Cockpit
Stem
Ghost Dia. 31.8 mm
Handlebar
GHOST Dia. 31.8 mm 680 mm
Grips
Velo VLG-1751D2
Seat
Saddle
Justek 3050 HRN
Seatpost
GHOST SP DC1 31.6 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.627 mm | 1.631 mm | 1.66 mm | 1.695 mm |
| Front Center | 657 mm | 660 mm | 664 mm | 673 mm |
| Rake | 50 mm | 49 mm | 50 mm | 50 mm |
| Trail | 74 mm | 75 mm | 67 mm | 67 mm |
| Stack | 636 mm | 641 mm | 664 mm | 683 mm |
| Reach | 391 mm | 393 mm | 400 mm | 403 mm |
| Top Tube Length | 580 mm | 595 mm | 610 mm | 625 mm |
| Seat Tube Angle | 73.5 ° | 72.5 ° | 72.5 ° | 72 ° |
| Seat Tube Length | 470 mm | 520 mm | 570 mm | 620 mm |
| Head Tube Angle | 70 ° | 70 ° | 71 ° | 71 ° |
| Head Tube Length | 160 mm | 165 mm | 185 mm | 205 mm |
| Chainstay Length | 455 mm | 455 mm | 455 mm | 455 mm |
| Wheelbase | 1105 mm | 1108 mm | 1112 mm | 1121 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 735 mm | 770 mm | 815 mm | 855 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 162 cm | 170 cm | 178 cm | 186 cm |
| Rider Max Height | 172 cm | 180 cm | 188 cm | 197 cm |
