Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 63mm -
Fork Suntour NEX
-
Groupset Tourney, Acera -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
151cm - 162cm
SM
160cm - 170cm
MD
168cm - 178cm
LG
176cm - 189cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
SQUARE TREKKING AL
Suspension Fork
SR Suntour NEX DS 63 mm
Drivetrain
Rear Derailleur
Shimano Acera RD-M3020 8-S
Cassette
Shimano CS-HG31 11-34
Crank
Shimano FC-TY301 48-38-28
Bottom Bracket
Thun Jive 3.0 FS
Chain
KMC Z51
Pedals
FPD NW-499
Wheels
Rims
Front: Rodi Excalibur XC19, Rear: Rodi Excalibur XC19
Tires
Front: Schwalbe Energizer Activ Plus 37-622, Rear: Schwalbe Energizer Activ Plus 37-622
Brakes
Brakes
Shimano BR-MT200 160 mm Disc
Brake Levers
Shimano BL-MT200
Cockpit
Stem
Ghost Dia. 31.8 mm
Handlebar
GHOST Dia. 31.8 mm 680 mm
Grips
Velo VLG-1752D2
Seat
Saddle
Justek 3050 HRN
Seatpost
GHOST SP DC1 31.6 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.709 mm | 1.718 mm | 1.71 mm | 1.676 mm |
| Front Center | 625 mm | 628 mm | 643 mm | 664 mm |
| Rake | 49 mm | 50 mm | 50 mm | 50 mm |
| Trail | 72 mm | 71 mm | 71 mm | 71 mm |
| Stack | 629 mm | 634 mm | 648 mm | 662 mm |
| Reach | 368 mm | 369 mm | 379 mm | 395 mm |
| Top Tube Length | 560 mm | 575 mm | 590 mm | 610 mm |
| Seat Tube Angle | 73 ° | 72 ° | 72 ° | 72 ° |
| Seat Tube Length | 420 mm | 470 mm | 520 mm | 560 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 150 mm | 155 mm | 170 mm | 185 mm |
| Chainstay Length | 455 mm | 455 mm | 455 mm | 455 mm |
| Wheelbase | 1073 mm | 1076 mm | 1091 mm | 1112 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 630 mm | 625 mm | 625 mm | 625 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 151 cm | 160 cm | 168 cm | 176 cm |
| Rider Max Height | 162 cm | 170 cm | 178 cm | 189 cm |
