Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 140mm -
Fork Giant STL 34
-
Groupset CUES -
Suspension Hardtail -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
163cm - 173cm
MD
170cm - 181cm
LG
178cm - 188cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX SL-grade aluminum, 12x148mm thru-axle
Suspension Fork
Giant STL 34, RCL, 140mm, 44mm offset, Boost 15x110
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano CUES RD-U6000
Front Derailleur
N/A
Shift Levers
Shimano CUES SL-6000, 1x10
Cassette
Shimano CUES, CS-LG300, 11x48
Crank
Shimano CUES FC-U6000, 30t S:170mm, M:170mm, L:170mm, XL:170mm
Bottom Bracket
Shimano, threaded
Chain
KMC X-11
Wheels
Front Hub
alloy, sealed
Rear Hub
alloy, sealed
Rims
Giant AM 27.5, tubeless ready sleeve-joint rim, 30mm inner width
Spokes
stainless
Tires
[F] Maxxis Ardent Race 27.5x2.6", EXO/TR[R] Maxxis Ardent Race 27.5x2.6", foldable, EXO/T
Brakes
Brakes
Shimano BR-MT420, hydraulic, Shimano RT-26 rotors [F]180mm, [R]180mm
Brake Levers
Shimano MT-401
Cockpit
Stem
Giant Contact SL 35 S:40mm, M:40mm, L:50mm, XL:50mm
Handlebar
Giant Contact SL TR35, 780x35mm
Grips
Giant Sole-O
Seat
Saddle
Giant Romero
Seatpost
Giant Contact Switch AT dropper, remote S: 110-140mm travel / 30.9 x 395mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.464 mm | 1.398 mm | 1.343 mm |
| Bottom Bracket Height | 295 mm | 295 mm | 295 mm |
| Front Center | 726 mm | 746 mm | 774 mm |
| Rake | 44 mm | 44 mm | 44 mm |
| Trail | 113 mm | 113 mm | 113 mm |
| Stack | 622 mm | 622 mm | 631 mm |
| Reach | 425 mm | 445 mm | 470 mm |
| Top Tube Length | 592 mm | 612 mm | 639 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 380 mm | 430 mm | 465 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 95 mm | 95 mm | 105 mm |
| Chainstay Length | 438 mm | 438 mm | 438 mm |
| Wheelbase | 1157 mm | 1177 mm | 1206 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm |
| Standover Height | 708 mm | 727 mm | 746 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 163 cm | 170 cm | 178 cm |
| Rider Max Height | 173 cm | 181 cm | 188 cm |
