Giant Propel Advanced Pro 0 AXS 2025
2025 Road
Estimate price |
8,805$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Groupset Force, Force eTap -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes SRAM Force Hydraulic Disc
Sizing
Recommended size guide.
SM
165cm - 175cm
MD
171cm - 181cm
MD/LG
177cm - 187cm
LG
183cm - 193cm
XL
189cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Advanced-Grade Composite, 12x142mm thru-axle, disc
Suspension Fork
Advanced SL-Grade Composite, full-composite OverDrive Aero steerer, 12x100mm thru-axle, disc
Rear Shock
N/A
Drivetrain
Rear Derailleur
SRAM Force AXS
Front Derailleur
SRAM Force AXS
Shift Levers
SRAM Force eTap AXS 2x12
Cassette
SRAM Force, 12-speed, 10x33
Crank
SRAM Force D2 DUB, 35/48 with power meter
Bottom Bracket
SRAM, press fit
Chain
SRAM Force D1
Pedals
PEDALS NOT SUPPLIED
Wheels
Front Hub
[F] Giant Low Friction Hub, CenterLock, [R] Giant Low Friction Hub, 30t ratchet driver, CenterLock, 12mm thru-axle
Rear Hub
[F] Giant Low Friction Hub, CenterLock, [R] Giant Low Friction Hub, 30t ratchet driver, CenterLock, 12mm thru-axle
Rims
Giant SLR 1 50 Carbon Disc WheelSystem, [F]50mm, [R]50mm
Spokes
Sapim
Tires
CADEX Road Race, tubeless, 700x25c (26.5mm), folding
Brakes
Brakes
SRAM Force hydraulic, SRAM PaceLine X rotors [F]160mm, [R]140mm
Brake Levers
SRAM Force eTap AXS hydraulic
Cockpit
Stem
Giant Contact SL Aero
Handlebar
Giant Contact SLR Aero
Grips
Stratus Lite 2.0
Seat
Saddle
Giant Fleet SL
Seatpost
Giant Vector, composite, -5/+15mm offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | MD/LG | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.379 mm | 1.405 mm | 1.43 mm | 1.445 mm | 1.447 mm |
| Bottom Bracket Height | 266 mm | 266 mm | 269 mm | 269 mm | 269 mm |
| Front Center | 582 mm | 585 mm | 595 mm | 610 mm | 624 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 62.5 mm | 57.8 mm | 57.8 mm | 57.8 mm | 57.8 mm |
| Stack | 528 mm | 545 mm | 562 mm | 581 mm | 596 mm |
| Reach | 383 mm | 388 mm | 393 mm | 402 mm | 412 mm |
| Top Tube Length | 535 mm | 550 mm | 565 mm | 580 mm | 600 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 500 mm | 520 mm | 545 mm | 575 mm | 595 mm |
| Head Tube Angle | 72.3 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Length | 130 mm | 145 mm | 165 mm | 185 mm | 200 mm |
| Chainstay Length | 405 mm | 405 mm | 405 mm | 405 mm | 405 mm |
| Wheelbase | 977 mm | 980 mm | 991 mm | 1006 mm | 1020 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 67 mm | 67 mm | 67 mm |
| Standover Height | 753 mm | 770 mm | 794 mm | 821 mm | 834 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 165 cm | 171 cm | 177 cm | 183 cm | 189 cm |
| Rider Max Height | 175 cm | 181 cm | 187 cm | 193 cm | 199 cm |
