Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 650b -
Groupset Deore, FSA -
Suspension Rigid -
Motor Yamaha 500W 80Nm mid-drive -
Battery Giant EnergyPak500, 36V, 13.8Ah, Rechargeable Lithium-Ion -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX SL-grade aluminum
Suspension Fork
ALUXX SL-grade aluminum, OverDrive
Drivetrain
Rear Derailleur
Shimano Deore Shadow
Front Derailleur
Shimano Deore
Shift Levers
Shimano Deore
Cassette
Shimano HG50-10 11x36, 10-Speed
Crank
FSA, 36/48
Chain
KMC X.10e, E-Bike Specific
Pedals
Alloy Platform
Wheels
Front Hub
Giant Sport Tracker Disc, 32h
Rear Hub
Giant Sport Tracker Disc, 32h
Rims
Giant Alloy, Double Wall
Spokes
Stainless Steel, 14g
Tires
Schwalbe Big Ben, 27.5x2
Brakes
Brakes
Shimano M315, hydraulic disc, [F] 180mm, [R] 160mm
Brake Levers
Shimano M315
Cockpit
Stem
Alloy, forged
Handlebar
Alloy, 31.8mm
Seat
Saddle
Giant Contact Upright
Seatpost
Alloy, 30.9mm
Motor & Battery
Motor
Giant SyncDrive Sport, 80Nm, 500W, Powered by Yamaha
Battery
Giant EnergyPak500, 36V, 13.8Ah, Rechargeable Lithium-Ion
Remote
Giant RideControl EVO, grip launch control with walk assist, mini USB charger
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.51 mm | 1.52 mm | 1.49 mm | 1.53 mm |
| Front Center | 586 mm | 591 mm | 610 mm | 619 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 79 mm | 76 mm | 76 mm | 76 mm |
| Stack | 580 mm | 592 mm | 606 mm | 625 mm |
| Reach | 385 mm | 390 mm | 406 mm | 408 mm |
| Top Tube Length | 551 mm | 571 mm | 591 mm | 611 mm |
| Seat Tube Angle | 74 ° | 73 ° | 73 ° | 72 ° |
| Seat Tube Length | 435 mm | 485 mm | 535 mm | 585 mm |
| Head Tube Angle | 70.5 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 135 mm | 145 mm | 160 mm | 180 mm |
| Chainstay Length | 456 mm | 456 mm | 456 mm | 456 mm |
| Wheelbase | 1032 mm | 1037 mm | 1057 mm | 1066 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 719 mm | 749 mm | 783 mm | 818 mm |
| Wheels | 650 | 650 | 650 | 650 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Quick-E+ is part of the Giant E Quick E model. 2 e-bikes variations carry this model name so far.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Commuter e-bikes
According to our math, the average price for a trustworthy Commuter e-bike is 2569$. However, you could also get a good Commuter e-bike even if you pay a lower amount than the average price. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
When Giant released this model in 2018, its price was 3115$. If we compare this with the average Commuter e-bike cost we notice that the price is 21.25% higher.
Quick-E+ components
Fork material
The fork is made out of aluminum, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels size
When leaving the production line, the Quick-E+ model has aluminum wheels. After 700c wheels, 650b is the second most popular choice for road bikes. However, they don’t perform so well when you go over bumps and obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Quick-E+ comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
This e-bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
