Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 100mm -
Fork Giant Crest 34
-
Groupset microSHIFT Advent X -
Suspension Hardtail -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
Regular
140cm - 160cm
LG
155cm - 170cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX-grade aluminum, horizontal dropouts, integrated chain tensioner
Suspension Fork
Giant CREST 34 Boost RCL, 15x110mm, 100mm
Rear Shock
N/A
Drivetrain
Rear Derailleur
MicroSHIFT Advent X RD-M6205
Front Derailleur
N/A
Shift Levers
MicroSHIFT Advent X SL-M9605
Cassette
MicroSHIFT Advent X CS-H104, 11x48
Crank
Prowheel Charm, 30t, 155mm (regular) Prowheel Charm, 30t, 155mm (large)
Bottom Bracket
threaded
Chain
KMC X10
Pedals
platform
Wheels
Front Hub
Giant Disc, 28h, 100x15 thru-axle, alloy, disc
Rear Hub
Giant Disc, 28h, 100x15 thru-axle, alloy, disc
Rims
Giant 26", alloy, 28mm inner width
Spokes
stainless, 14g
Tires
Maxxis Ikon, 26x2.2"
Brakes
Brakes
Tektro HD-M275, hydraulic [F]180mm, [R]160mm rotors
Brake Levers
Tektro HD-M275
Cockpit
Stem
forged alloy, 0-degree
Handlebar
Giant Sport, alloy, 31.8mm
Grips
Giant Sole-O
Seat
Saddle
Giant Sport
Seatpost
alloy, two-bolt, 30.9x300mm (regular) alloy, two-bolt, 30.9x350mm (large)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | Regular | LG |
|---|---|---|
| Stack Reach Ratio | 1.548 mm | 1.466 mm |
| Stack | 579 mm | 588 mm |
| Reach | 374 mm | 401 mm |
| Top Tube Length | 545 mm | 575 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° |
| Head Tube Angle | 67 ° | 67 ° |
| Head Tube Length | 100 mm | 110 mm |
| Chainstay Length | 435 mm | 435 mm |
| Wheelbase | 1086 mm | 1117 mm |
| Standover Height | 679 mm | 717 mm |
| Wheels | 26" | 26" |
| Rider Min Height | 140 cm | 155 cm |
| Rider Max Height | 160 cm | 170 cm |
