Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Travel Front 100mm -
Fork Giant Crest 34
-
Groupset SLX -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
163cm - 173cm
MD
170cm - 181cm
LG
178cm - 189cm
XL
186cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX SLR-grade Aluminum, 12x148mm thru-axle
Suspension Fork
Giant Crest 34 RRL, 100mm, 15x110, remote lockout
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano SLX M7100
Front Derailleur
N/A
Shift Levers
Shimano SLX M-7100, 1x12
Cassette
Shimano SLX, 10x51
Crank
Shimano SLX, 32t S:170mm, M:175mm, L:175mm, XL:175mm
Bottom Bracket
Shimano, press fit
Chain
KMC X-12
Pedals
N/A
Wheels
Front Hub
Shimano C500, sealed
Rear Hub
Shimano C500, sealed
Rims
Giant XCT 29, 25mm inner width
Spokes
stainless
Tires
Maxxis Recon Race 29x2.4, foldable, TLR, EXO, tubeless
Brakes
Brakes
Shimano BR-MT500, hydraulic, Shimano RT-10 rotors [F]180mm, [R]160mm
Brake Levers
Shimano BR-MT501
Cockpit
Stem
Giant Contact S:60mm, M:70mm, L:80mm, XL:90mm
Handlebar
Giant Connect XC, 740x31.8mm
Grips
Giant Sole-O
Seat
Saddle
Giant ErgoContact Trail
Seatpost
Giant Contact Switch Core dropper, remote S: 100mm travel / 30.9 x 350mm M: 100mm travel / 30.9 x 350mm L:
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.442 mm | 1.38 mm | 1.349 mm | 1.295 mm |
| Bottom Bracket Height | 316 mm | 316 mm | 316 mm | 316 mm |
| Front Center | 683 mm | 702 mm | 718 mm | 749 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 94.9 mm | 94.9 mm | 94.9 mm | 94.9 mm |
| Stack | 607 mm | 607 mm | 618 mm | 628 mm |
| Reach | 421 mm | 440 mm | 458 mm | 485 mm |
| Top Tube Length | 595 mm | 614 mm | 635 mm | 665 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 380 mm | 431 mm | 475 mm | 525 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 70 ° | 70 ° |
| Head Tube Length | 95 mm | 95 mm | 105 mm | 115 mm |
| Chainstay Length | 440 mm | 440 mm | 440 mm | 440 mm |
| Wheelbase | 1117 mm | 1136 mm | 1152 mm | 1183 mm |
| Bottom Bracket Drop | 58 mm | 58 mm | 58 mm | 58 mm |
| Standover Height | 727 mm | 757 mm | 785 mm | 818 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 163 cm | 170 cm | 178 cm | 186 cm |
| Rider Max Height | 173 cm | 181 cm | 189 cm | 198 cm |
