Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Groupset microSHIFT Advent X -
Suspension Rigid -
Motor 250W mid-drive -
Battery Greyp custom battery pack, 36V, 700 Wh (Li-ion), OTA updatable -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
163cm - 177cm
LG
173cm - 187cm
XL
183cm - 197cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Greyp T5 frame AL6066, 2 bottle mounts
Suspension Fork
Greyp custom rigid fork, 2 bottle/bag mounts
Drivetrain
Rear Derailleur
Shimano Deore 10-Speed / Microshift Advent X 10-Speed
Shift Levers
Shimano Deore 10-Speed / Microshift Advent X Single Click 10-speed
Cassette
Shimano Deore 10-Speed / Microshift Advent X 10-speed
Crank
Greyp custom, 170mm, ISIS, Alloy forged
Chain
Shimano Deore 10-Speed / KMC e10 EPT
Pedals
VP-components VPE-506
Wheels
Rims
SUNringle Duroc SD37 Comp, Boost
Tires
Pirelli Angel XT, 29" x 2,25"
Brakes
Brakes
Formula Cura (2 pistons), 203mm / 180mm
Cockpit
Stem
Greyp custom 50mm with integrated CIM (Central Intelligence Module)
Handlebar
Riser bar 720mm
Grips
VP-components VPG-122A
Headset
VP-components VP-J305AC
Seat
Saddle
Selle Royal Essenza+
Seatpost
Satori XOPIC 2 Suspension seatpost
Motor & Battery
Motor
MPF 6.0C, custom firmware, 250W, 25km/h
Battery
Greyp custom battery pack, 36V, 700 Wh (Li-ion), OTA updatable
Charger
Greyp custom smart charger, 36V, 4A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL | Gobi Brown | Sonoran Blue |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.563 mm | 1.497 mm | 1.439 mm | mm | mm |
| Bottom Bracket Height | 320 mm | 320 mm | 320 mm | mm | mm |
| Front Center | 706 mm | 731 mm | 848 mm | mm | mm |
| Rake | 39 mm | 38 mm | mm | mm | mm |
| Trail | 106 mm | 107 mm | mm | mm | mm |
| Stack | 644 mm | 651 mm | 659 mm | mm | mm |
| Reach | 412 mm | 435 mm | 458 mm | mm | mm |
| Top Tube Length | 585 mm | 610 mm | 635 mm | mm | mm |
| Seat Tube Angle | 75 ° | ° | 75 ° | ° | ° |
| Seat Tube Length | 430 mm | 480 mm | 530 mm | mm | mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° | ° | ° |
| Head Tube Length | 133 mm | 142 mm | 150 mm | mm | mm |
| Chainstay Length | 480 mm | 480 mm | 480 mm | mm | mm |
| Wheelbase | 1180 mm | 1205 mm | 1323 mm | mm | mm |
| Bottom Bracket Drop | 57 mm | 57 mm | 57 mm | mm | mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 163 cm | 173 cm | 183 cm | cm | cm |
| Rider Max Height | 177 cm | 187 cm | 197 cm | cm | cm |
