Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Travel Front 80mm -
Fork Suntour XCM
-
Groupset Tourney -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
152cm - 167cm
MD
164cm - 179cm
LG
176cm - 187cm
XL
184cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
GT Alloy Triple Triangle, 27.5/29" Wheels, replaceable hanger
Suspension Fork
SR Suntour XCM, 80mm, Hydraulic Lockout
Drivetrain
Rear Derailleur
Shimano Tourney
Front Derailleur
Shimano TY600
Shift Levers
Shimano SL-M315, 8-speed
Cassette
Shimano Acera, 12-32T
Crank
Shimano TY301, 42/34/24T
Bottom Bracket
BSA, Square Taper
Chain
KMC Z8.3, 8-speed
Pedals
GT Slim Line Flat Pedal
Wheels
Front Hub
Alloy Disc, QR, 32H
Rear Hub
Alloy Disc Cassette QR, 32H
Rims
WTB SX19, 32h
Tires
Front: WTB Ranger Comp, DNA Compound, 27.5/29 x 2.25", Rear: WTB Ranger Comp, DNA Compound, 27.5/29 x 2.25"
Brakes
Brakes
Tektro M275 Hydro, 160/160mm Rotor
Cockpit
Stem
GT Alloy, 31.8, 8° up
Handlebar
GT Alloy Riser, 25mm Rise, 720mm Width, 6° up, 8° back
Grips
GT Statement
Headset
Semi-integrated, Sealed Cartridge
Seat
Saddle
GT MTB
Seatpost
GT All Terra Two Bolt Alloy
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 152 cm | 164 cm | 176 cm | 184 cm |
| Rider Max Height | 167 cm | 179 cm | 187 cm | 198 cm |
