Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Travel Front 100mm -
Fork Suntour XCM
-
Groupset microSHIFT Advent X -
Suspension Hardtail -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
142cm - 154cm
SM
152cm - 167cm
MD
165cm - 180cm
LG
177cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
GT Alloy Triple Triangle, 27.5/29" Wheels, replaceable hanger
Suspension Fork
SR Suntour XCM, 100mm, Hydraulic Lockout
Drivetrain
Rear Derailleur
microSHIFT RD-M6205GM
Front Derailleur
N/A
Shift Levers
microSHIFT M850, 10-speed
Cassette
Sunrace, 11-42T
Crank
Prowheel Charm, 32T
Bottom Bracket
BSA, Square Taper
Chain
KMC X10, 10-speed
Pedals
GT Slim Line Flat Pedal
Wheels
Front Hub
Alloy Disc, QR, 32H
Rear Hub
Formula, QRx141, 32H
Rims
WTB SX19, 32h
Tires
Front: WTB Ranger Comp, DNA Compound, 27.5/29 x 2.25", Rear: WTB Ranger Comp, DNA Compound, 27.5/29 x 2.25"
Brakes
Brakes
Tektro or Nutt Hydraulic Disc Brakes, 160/160mm Rotors
Cockpit
Stem
GT 3D Forged Alloy, 31.8, 80mm
Handlebar
GT Alloy Riser, 25mm Rise, 720mm Width, 6° up, 8° back
Grips
GT Statement
Headset
Semi-integrated, Sealed Cartridge, Tapered
Seat
Saddle
GT MTB
Seatpost
GT All Terra Two Bolt Alloy, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Wheels | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 142 cm | 152 cm | 165 cm | 177 cm | 185 cm |
| Rider Max Height | 154 cm | 167 cm | 180 cm | 188 cm | 198 cm |
