Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Travel Front 100mm -
Fork Suntour X1
-
Groupset microSHIFT -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
142cm - 154cm
SM
152cm - 167cm
MD
165cm - 180cm
LG
177cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
GT Alloy Triple Triangle, 27.5/29" Wheels, replaceable hanger
Suspension Fork
SR Suntour X1, 100mm
Drivetrain
Rear Derailleur
Microshift RD-M665M
Front Derailleur
N/A
Shift Levers
microSHIFT M851, 11-speed
Cassette
microSHIFT, 11-46T
Crank
Prowheel Charm, 32T
Bottom Bracket
BSA, Square Taper
Chain
KMC X11, 11-speed
Pedals
GT Slim Line Flat Pedal
Wheels
Front Hub
Alloy Disc, QR, 32H
Rear Hub
Formula, QRx141, 32H
Rims
WTB SX19, 32h
Tires
Front: Vittoria Barzo, 27.5/29 x 2.25", Rear: Vittoria Barzo, 27.5/29 x 2.25"
Brakes
Brakes
NUTT Y-2 Hydro, 160/160mm Rotors
Cockpit
Stem
GT 3D Forged Alloy, 31.8, 80mm
Handlebar
GT Alloy Riser, 25mm Rise, 720mm Width, 5° up, 9° back
Grips
GT Statement
Headset
Semi-integrated, Sealed Cartridge
Seat
Saddle
WTB Silverado Sport
Seatpost
GT All Terra Two Bolt Alloy, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Wheels | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 142 cm | 152 cm | 165 cm | 177 cm | 185 cm |
| Rider Max Height | 154 cm | 167 cm | 180 cm | 188 cm | 198 cm |
