Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 120mm -
Fork RockShox Recon Silver RL
-
Groupset SX Eagle -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 180cm
LG
177cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
GT Alloy Triple Triangle, 27.5/29" Wheels, replaceable hanger
Suspension Fork
RockShox Recon Silver RL, 120mm, 15x100, Remote Lockout, Maxle Lite
Drivetrain
Rear Derailleur
SRAM SX Eagle
Front Derailleur
N/A
Shift Levers
SRAM SX Eagle, 12-speed
Cassette
SRAM Eagle 11-50T
Crank
SRAM SX Eagle, 32T
Bottom Bracket
BSA, Truvativ Power Spline
Chain
SRAM SX Eagle, 12-speed
Pedals
GT Slim Line Flat Pedal
Wheels
Front Hub
Shimano MT400, 15x100, 32H
Rear Hub
Shimano MT200, QRx141, 32H
Rims
WTB ST i25 TCS 2.0, 32h, Tubeless Ready
Tires
Front: Vittoria Barzo, 27.5/29 x 2.25", Rear: Vittoria Barzo, 27.5/29 x 2.25"
Brakes
Brakes
Tektro M520 Hydro, 160/160mm Rotors
Cockpit
Stem
GT 3D Forged Alloy, 31.8, 80mm
Handlebar
GT Alloy Riser, 25mm Rise, 720mm Width, 5° up, 9° back
Grips
GT Statement
Headset
Semi-integrated, Sealed Cartridge, Tapered
Seat
Saddle
WTB Silverado Sport
Seatpost
GT All Terra Two Bolt Alloy, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 165 cm | 177 cm | 185 cm |
| Rider Max Height | 180 cm | 188 cm | 198 cm |
