Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 150mm -
Travel Rear 150mm -
Fork RockShox Yari RC
-
Groupset SX Eagle -
Suspension Full -
Motor Shimano 600W 85Nm mid-drive -
Battery Shimano BT-E8036, 630Wh -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
152cm - 167cm
MD
165cm - 180cm
LG
177cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
eForce Alloy 29” Frame, 150mm Travel, Shimano STEPS, 12x148mm Thru-Axle
Suspension Fork
RockShox Yari RC, 150mm, E-MTB, Motion Control, 42mm Offset
Rear Shock
RockShox Deluxe Select R, 185x55mm Trunnion
Drivetrain
Rear Derailleur
SRAM SX Eagle
Shift Levers
SRAM SX Eagle, 12-Speed
Cassette
SRAM PG-1210, 11-50T
Crank
FSA CK-752 EP8, 165mm, 34T
Bottom Bracket
STEPS, press-fit
Chain
SRAM SX Eagle, 12-Speed
Pedals
GT Slim Line Flat Pedal
Wheels
Front Hub
Formula, 15x110mm
Rear Hub
Formula, 12x148mm, HG Freehub Body
Rims
WTB STX i30 TCS, 32h, Tubeless Ready
Tires
Front: Maxxis Minion DHF, 29x2.6", 3C MaxxTerra, EXO+, Rear: Maxxis Minion DHR II, 29x2.6", 3C MaxxTerra, EXO+
Brakes
Brakes
Slate T4, 203/203mm Rotors
Cockpit
Stem
GT Alloy, 35mm
Handlebar
GT Alloy Riser Bar, 20mm Rise, 780mm, 5° Up, 8° Back
Grips
GT Statement Logo
Headset
FSA No.42
Seat
Saddle
WTB Silverado Sport
Seatpost
TranzX Dropper, 31.6mm, (S - 130mm, M - 150mm, L/XL - 170mm)
Motor & Battery
Motor
Shimano DU-EP801
Battery
Shimano BT-E8036, 630Wh
Charger
Shimano EC-E6000-1
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.452 mm | 1.371 mm | 1.299 mm | 1.252 mm |
| Bottom Bracket Height | 349.5 mm | 349.5 mm | 349.5 mm | 349.5 mm |
| Front Center | 756 mm | 781 mm | 806 mm | 835 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 121 mm | 121 mm | 121 mm | 121 mm |
| Stack | 617 mm | 617 mm | 617 mm | 626 mm |
| Reach | 425 mm | 450 mm | 475 mm | 500 mm |
| Top Tube Length | 579 mm | 604 mm | 629 mm | 656 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 430 mm | 450 mm | 480 mm | 510 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 115 mm | 115 mm | 115 mm | 124 mm |
| Chainstay Length | 455 mm | 455 mm | 455 mm | 455 mm |
| Wheelbase | 1209 mm | 1234 mm | 1259 mm | 1288 mm |
| Bottom Bracket Drop | 30 mm | 30 mm | 30 mm | 30 mm |
| Standover Height | 735 mm | 739 mm | 755 mm | 776 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 152 cm | 165 cm | 177 cm | 185 cm |
| Rider Max Height | 167 cm | 180 cm | 188 cm | 198 cm |
